MINI UHF RFID Tag Wroking on Metal

US$ 1.5 - 2.6 MOQ: 1000 Pieces

Key Specifications

Brand Name:

HCT

Model Number:

HCT-Fit 200

Hongchangtag Tech-Sci Development Inc.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Brand Name HCT

Model Number HCT-Fit 200

With its extremely small form factor, Fit 200 tags are ideally suited to tracking small metal assets including attachments to:

1. Small hand tools including sockets

2. Metal IT assets including covert tagging.

3. Medical devices.

RF Specifications
Protocol	EPC Class 1 Gen2
Frequency Range (MHz)	860-940 (GS)
Read Range (Fixed reader)	1.Up to 2.5m (8.2ft)
Read Range (Handheld reader)	Up to 1.25m(4.1ft)
Material Compatibility	On metal only
IC Type (chip)	Alien H3
Memory	EPC - 96bit User - 512bits TID - 64bits
Note 1. Quoted performance achieved using standard testing methodology. Read range will vary with Reader hardware and output power. 2. EPC and User memory are reprogrammable, TID is locked at point of manufacture
Physical Specifications
Encasement	Durable paint
Size (mm)	8.6x 6.1 x 2.6(mm)(+/- 0.5) /0.34 x 0.24 x 0.(in) (+/- 0.2)
Weight	0.8g
Environmental Specifications
Operating Temperature	–40 ° to +85 °C
Long term Max Temperature	exposure - (days, weeks, years) +120 °C
Short term Max Temperature	exposure - (minutes,hours) +150 °C
IP Rating	IP68
Attachment	Permanent liquid adhesive (not included),Film adhesive(optional)
Warranty	1 year
