Android EPC C1 GEN2/ ISO 18000-6C Rfid Bluetooth Card Reader

Product introduction

CF-H501 reader is a super small UHF RFID read and write device that can be long time standby. Beautiful appearance, compact size, easy to take and with 0.95` true color, OLED screen. It can display the number of the tag, the operation interface for user-friendly, user operation more convenient, intuitive. It can store the tag data offline, upload tag data via Bluetooth. The reader can support the protocol of EPC C1 G2/ISO 18000-6C. The target market is for the occasions which need of portable, low cost, mobile data acquisition such as Anti-fake, Logistics, Equipment inspection, etc.

Features

Working frequency: 840~930MHz(According to the demands, FHSS)

Protocol: EPC C1 GEN2/ ISO 18000-6C

Bluetooth: 3.0 EDR+4.0 BLE dual mode

It can achieve 100meters over the remote communication under the open environment and BLE equipment

Storage: Store 100tag data offline, upload  via Bluetooth

USB: Micro USB, the virtual U disk device, store upgrade file

Firmware upgrade:Firmware upgrade  offline via update and upgrade file

Working voltage: Lithium 3.7V/780mAh,  charge by general micro USB cable

Working time: Work more than 3hours for continuous reading tag

Operating temperature: 0℃~55℃

Storage temperature: -10℃~70℃

Outline size: 88mm*39mm*16mm

Keys: 4functional keys

Display: 0.95` true color, OLED screen

Voice: Speaker

Distance of read and write tags: Alien 9662 tag read distance is about 10~15cm

Provide Bluetooth API and demo program under PC and Android, IOS not support
