rj232 usb desktop uhf rfid writer/reader can add TJ45 interface
Product mode explanation
|
Model |
Interface |
|
CF-RU5104 |
RS232 |
|
CF-RU5104T |
RS232 and TCP/IP |
CF-RU5104 is a high performance Multiple Protocol UHF RFID Reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.
FEATURES
1. Self-intellectual property;
2. Support ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag;
3. 902~928MHz/865~868Mhz frequency band(frequency customization optional);
4. FHSS or Fix Frequency transmission;
5. RF output power up to 30dbm(adjustable);
6. Built-in wideband antenna with effect distance up to 0~100cm;
7. Support auto-running and interactive work mode;
8. Low power dissipation with single +9V DC power supply;
9. Support RS232/RS485, TCP/IP, Weigand, interface;
10. Output format and parameters configurable;
11. Provide SDK and demo software to facilitate further development.
* Effective distance depends on protocol, tag and environment
CHARACTERISTICS
Absolute Maximum Rating
|
ITEM |
SYMBOL |
VALUE |
UNIT |
|
Power Supply |
VCC |
16 |
V |
|
Operating Temp. |
TOPR |
-10~+60 |
℃ |
|
Storage Temp. |
TSTR |
-25~+80 |
℃ |
Electrical and Mechanical Specification
Under TA=25℃,VCC=+9V unless specified
|
ITEM |
SYMBOL |
MIN |
TYP |
MAX |
UNIT |
|
Power Supply |
VCC |
6 |
9 |
12 |
V |
|
Current Dissipation |
IC |
|
350 |
650 |
mA |
|
Frequency |
FREQ |
902 |
|
928 |
MHz |
|
Effective Distance* |
Dis |
0 |
100 |
500 |
|
* Effective distance depends on protocol, tag and environment.
