Home > Security & Protection > Access Control System > Access Control Card Reader > Supports NFC+ Fingerprint +print+ WiFi +BT+ GPS+ Camera Andriod Tablet Reader
Supports NFC+ Fingerprint +print+ WiFi +BT+ GPS+ Camera Andriod Tablet Reader
US$ 220 - 260
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chafon
Model Number:
H801
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3.5mm Audio Interface Uhf Vhf RadioUS$ 104 - 109MOQ: 1 Piece -
High Sacn Rate Long Distance Bluetooth Rfid ReaderUS$ 220 - 250MOQ: 1 Piece
-
Professional Manufacturer Reader Bluetooth RfidUS$ 220 - 250MOQ: 1 Piece
-
Long Distance Uhf Handheld Bluetooth ReaderUS$ 220 - 250MOQ: 1 Piece
-
High Scan Rate Handheld Wireless Uhf Rfid ReaderUS$ 220 - 250MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Chafon
Model Number
H801
supports NFC+ Fingerprint +print+ WiFi +BT+ GPS+ camera andriod tablet reader
Product Description
Product Description
1.tablet USB IC card and magnetic card reader
2.Operation System: Andorid 4.4, multi-language
3.CPU: MTK8382 Corte quad-core, 1.3GHZ*4
4.Color: Silver
5.Screen:7'' IPS 1024*600
6.Memory: 1GB+8GB
7.Size: 198mm*117mm*12.8mm
8.Camera: 2MP+5MP
9.Battery: 3.7V/1000mAh, 8-24 hours
10.Function: NFC+ Fingerprint +print+ WiFi +BT+ GPS+ camera
| System Physical Standard Configuration | ||
| type | detail | descriptions |
| product form | product form | straight plate |
| dimensions | 198mm*117mm*12.8mm | |
| LCD | screen size | 7''16:9 |
| screen resolution | 1024*600IPS/AFFS | |
| TP | touch module | capacity multi-touch panel 5 points capacity screen/toughened glass TP |
| battery | type | lithium-ion polymer battery |
| capacity | 3.7V/10000mAh | |
| endurance | 8-24hours | |
| Industrial protection | ||
| drop test | rugged | |
| humidity | waterproof | 5%-95%RH |
| temperature | rugged | -25'C-65'C |
| IP | rate | IP54 |
| System hardware configuration | ||
| CPU | type | MTK8382Corte quad-core |
| speed | 1.3Ghz*4 | |
| GPU | type | dual mali 400 |
| speed | dual 400MHz | |
| molti-media(hardware decoding) | photo viewer | BMP,JPG,GIF,PNG |
| video format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC1, MVC,AVS,MJPEG.(UP TO 1080P) | |
| audio format | MP3,WMA,WAV,OGG,FLAC,APE,AAC,AC-3,DTS(need license) | |
| RAM | AAR3 | 1GB DDR3 |
| ROM Flash | nand flash | 16GB(8GB/16GB/32GB/64GB optional) |
| camera | front facing | 2.0MP |
| rear facing | 5.0MP auto focused | |
| speaker | size | built-in 8Ω/1.5W speaker |
| G-sensor | built-in | 3 axis gravity acceleration sensor |
| GPS | built-in | built-in |
| Network Connections | ||
| wifi | wifi module | wifi 802.11b/g/n |
| bluetooth | built-in | BT4.0 |
| 3G | built-in | WCDMA/EVDO/TD-SCNMA(optional), support voice calls |
| ethernet network | mini USB switch to ethernet network | supportive |
| Interface Configuration | ||
| memory card socket | external menor | micro, mini SD, TF card |
| USB interface | Data transfer supportive | USB OTG |
| 3G interface | SIM interface | built-in |
| DC connector | power | 2.5mm power connector |
| keyboard | input device | wired/wireless supportive |
| mouse | input device | wired/wireless supportive |
| Necessary Accessories | ||
| power adapter | standard configuration | 5V/2A |
| USB data cable | standard configuration | connect to PC |
| USB patch cord | standard configuration | OTG to HOST(adjustable) |
| Software Configuration | ||
| operating system | opterating system version | Andriod 4.4.2 |
| language | multi-language supportive | |
| flash | flash 10.3;hardware decoding supportive | |
| html5 | supportive | |
| Application modules | chipset/module | NFC chip, 128K/C2 ROM44KB EEROM |
| NFC/HF RFID optional | RF frequency | 13.56MHz |
| work range | <5cm | |
| protocol | can be read with a iso 1443A/B, ISO15693,Mifare,Felia agreement | |
| the point-to-point data transmission(P2P mode) | ||
| fingerprint features | image pixel | 500dpi |
| security level | five level(from low to high:1,2,3,4,5) | |
| fingerprint image edit time | <0.5second | |
| fingerprint features | 512bytes(valid data is 256 bytes) | |
| IC card | support | ISO7816, PC/SC |
| magnetic stripe card | support | ISO-7811,7812 |
Reader&writer, we will provide SDK, demo software and user manual, you can use the demo software to read&write.
