Tablet USB IC Card and Magnetic Card Reader With Multifuntional
US$ 220 - 260
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chafon
Model Number:
H801
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Performance Card Tablet Reader/writer With WiFi /BT/GPS/ CameraUS$ 220 - 260MOQ: 1 Piece -
Supports NFC+ Fingerprint +print+ WiFi +BT+ GPS+ Camera Andriod Tablet ReaderUS$ 220 - 260MOQ: 1 Piece
-
3.5mm Audio Interface Uhf Vhf RadioUS$ 104 - 109MOQ: 1 Piece
-
High Sacn Rate Long Distance Bluetooth Rfid ReaderUS$ 220 - 250MOQ: 1 Piece
-
Professional Manufacturer Reader Bluetooth RfidUS$ 220 - 250MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Chafon
Model Number
H801
tablet USB IC card and magnetic card reader with multifuntional
Product Description
Product Description
1.tablet USB IC card and magnetic card reader
2.Operation System: Andorid 4.4, multi-language
3.CPU: MTK8382 Corte quad-core, 1.3GHZ*4
4.Color: Silver
5.Screen:7'' IPS 1024*600
6.Memory: 1GB+8GB
7.Size: 198mm*117mm*12.8mm
8.Camera: 2MP+5MP
9.Battery: 3.7V/1000mAh, 8-24 hours
10.Function: NFC+ Fingerprint +print+ WiFi +BT+ GPS+ camera
| System Physical Standard Configuration | ||
| type | detail | descriptions |
| product form | product form | straight plate |
| dimensions | 198mm*117mm*12.8mm | |
| LCD | screen size | 7''16:9 |
| screen resolution | 1024*600IPS/AFFS | |
| TP | touch module | capacity multi-touch panel 5 points capacity screen/toughened glass TP |
| battery | type | lithium-ion polymer battery |
| capacity | 3.7V/10000mAh | |
| endurance | 8-24hours | |
| Industrial protection | ||
| drop test | rugged | |
| humidity | waterproof | 5%-95%RH |
| temperature | rugged | -25'C-65'C |
| IP | rate | IP54 |
| System hardware configuration | ||
| CPU | type | MTK8382Corte quad-core |
| speed | 1.3Ghz*4 | |
| GPU | type | dual mali 400 |
| speed | dual 400MHz | |
| molti-media(hardware decoding) | photo viewer | BMP,JPG,GIF,PNG |
| video format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC1, MVC,AVS,MJPEG.(UP TO 1080P) | |
| audio format | MP3,WMA,WAV,OGG,FLAC,APE,AAC,AC-3,DTS(need license) | |
| RAM | AAR3 | 1GB DDR3 |
| ROM Flash | nand flash | 16GB(8GB/16GB/32GB/64GB optional) |
| camera | front facing | 2.0MP |
| rear facing | 5.0MP auto focused | |
| speaker | size | built-in 8Ω/1.5W speaker |
| G-sensor | built-in | 3 axis gravity acceleration sensor |
| GPS | built-in | built-in |
| Network Connections | ||
| wifi | wifi module | wifi 802.11b/g/n |
| bluetooth | built-in | BT4.0 |
| 3G | built-in | WCDMA/EVDO/TD-SCNMA(optional), support voice calls |
| ethernet network | mini USB switch to ethernet network | supportive |
| Interface Configuration | ||
| memory card socket | external menor | micro, mini SD, TF card |
| USB interface | Data transfer supportive | USB OTG |
| 3G interface | SIM interface | built-in |
| DC connector | power | 2.5mm power connector |
| keyboard | input device | wired/wireless supportive |
| mouse | input device | wired/wireless supportive |
| Necessary Accessories | ||
| power adapter | standard configuration | 5V/2A |
| USB data cable | standard configuration | connect to PC |
| USB patch cord | standard configuration | OTG to HOST(adjustable) |
| Software Configuration | ||
| operating system | opterating system version | Andriod 4.4.2 |
| language | multi-language supportive | |
| flash | flash 10.3;hardware decoding supportive | |
| html5 | supportive | |
| Application modules | chipset/module | NFC chip, 128K/C2 ROM44KB EEROM |
| NFC/HF RFID optional | RF frequency | 13.56MHz |
| work range | <5cm | |
| protocol | can be read with a ISO14443A/B, ISO15693,Mifare,Felia agreement | |
| the point-to-point data transmission(P2P mode) | ||
| fingerprint features | image pixel | 500dpi |
| security level | five level(from low to high:1,2,3,4,5) | |
| fingerprint image edit time | <0.5second | |
| fingerprint features | 512bytes(valid data is 256 bytes) | |
| IC card | support | ISO7816, PC/SC |
| magnetic stripe card | support | ISO-7811,7812 |
Reader&writer, we will provide SDK, demo software and user manual, you can use the demo software to read&write.
