RFID android barcode scanner with wifi,bluetooth,3g,gprs,gps,camera function
CF-H901 is a IP65 industrial-grade handheld reader, support Android 4.2 OS,with Cortex A9 1.2GHz processor,include GPRS,WCDMA,WIFI,Bluetooth etc function,can add RFID function,include 125KHz,13.56MHz,UHF,2.45G for option.
Features | ||||||||||||||||||||||||
The processor |
Cortex A9 1.2GHZ The processor |
|||||||||||||||||||||||
Memory capacity |
ROM:EMMC 32Gb RAM: LPDDR2 8Gb |
|||||||||||||||||||||||
The operating system |
Android 4.22 |
|||||||||||||||||||||||
Wireless communications |
GPRS |
GPRS, EDGE , 4-band 900/1800,850/1900 |
||||||||||||||||||||||
WCDMA |
band 850/2100,Cat.8 HSDPA Cat.6 HSUPA |
|||||||||||||||||||||||
WIFI |
Conform to the IEEE 802.11b/g |
|||||||||||||||||||||||
Bluetooth |
Conform to the Bluetooth 4.0 |
|||||||||||||||||||||||
Display |
4.3 inch IPS display, The resolution of the 480*800, Gabo Lingual perspective, the sun is visible |
|||||||||||||||||||||||
Touch screen |
Support more capacitive touch |
|||||||||||||||||||||||
Indicator light |
Network indicator light, charge indicator |
|||||||||||||||||||||||
audio |
Support the speech |
|||||||||||||||||||||||
Micro SD card |
Support 32 gb MICRO SD card |
|||||||||||||||||||||||
Data security |
Product is the data security protection, in a completely off electricity (remove the battery and the power converter), data is not lost |
|||||||||||||||||||||||
|
GPS indicators (Optional) |
Channel: channel 12 Receive types: L1, C/A code and carrier phase smoothing Heavy capture: < 1 s The latest ASIC chip; A squadron of patent algorithms; EVEREST multipath suppression technology Error range: < = 10 meters |
|||||||||||||||||||||||
Navigation map |
Support navione, baidu, Google, gold and other navigation map |
|||||||||||||||||||||||
The input method |
Full-screen handwriting, half screen handwriting, strokes and pinyin, Numbers, letters, symbols |
|||||||||||||||||||||||
Physical interface |
High-speed USB2.0 interface equipment end, 3.5 stick related plug-in interface |
|||||||||||||||||||||||
camera(Optional) |
The rear 500 w megapixel camera with flash |
|||||||||||||||||||||||
The flashlight |
Low power consumption LED lights lighting, emergency use |
|||||||||||||||||||||||
The fingerprint module(Optional) |
Sensor types: inductive, image size: 256 * 288, image resolution: 500 dpi |
|||||||||||||||||||||||
Registration time < 3 seconds, compare the time < < 0.1 s, than in time of 0.5 seconds (100) | ||||||||||||||||||||||||
Boomed from < 0.1%, recognize false rate < 0.001%, fingerprint capacity: 512 | ||||||||||||||||||||||||
A dimensional barcode(MOTO-SE655)(Optional) | ||||||||||||||||||||||||
Read code system |
Can read all kinds of main one-dimensional bar code: Code 39,Code 93,Code 128,Codebar,EAN-13,EAN-8,UPC-A,UPC-E,ITF 14,UCC/EAN-128,ITF 25,Matrix 25,EAN-128,ISBN |
|||||||||||||||||||||||
Read distance |
0 cm~50 cm |
|||||||||||||||||||||||
Read rate |
First read rate of 99% or more, the error rate of 0.01% or less, false reject rate is 0.01% or less |
|||||||||||||||||||||||
Two dimensional barcode(Optional) | ||||||||||||||||||||||||
Moto-SE4500 |
Hardware decoding, the decoding speed and error rate of 0.01% or less |
|||||||||||||||||||||||
Honeywell-5180 |
Hardware decoding, the decoding speed and error rate of 0.01% or less |
|||||||||||||||||||||||
RFID (Optional) | ||||||||||||||||||||||||
Ultra high frequency |
0~1m distance for EPC C1 GEN2 / ISO18000-6 - c protocol of 900 MHZ tag read operation (associated with tags and antenna) |
|||||||||||||||||||||||
High frequency |
0 ~ 7 cm range for ISO15693, ISO14443 double deal 13.56 MHz tags for reading and writing (associated with tags and antenna) |
|||||||||||||||||||||||
Low frequency |
125 K / 134.2 K animal ear tag |
|||||||||||||||||||||||
PSAM |
Support two PSAM card |
|||||||||||||||||||||||
High frequency (CPU card read) |
Support the CPU card read and write, used with PSAM |
|||||||||||||||||||||||
Active in close communication(Optional Customers need to provide module) | ||||||||||||||||||||||||
Active 2.45 G |
Distance is 200 m, 200 m label can be read all at once |
|||||||||||||||||||||||
433M |
Read more than 200 m distance, distance is adjustable |
|||||||||||||||||||||||
Battery performance | ||||||||||||||||||||||||
The battery |
4100 mah lithium polymer battery, standby time: more than 150 hours, working time: more than 8 hours, ac adapter charging (1 a) |
|||||||||||||||||||||||
The battery standby time |
After a full charge, the wireless communication function on standby, after 360 hours, can run normally |
|||||||||||||||||||||||
Battery charging time |
Charging time < 4.5 hours |
|||||||||||||||||||||||
Charging time |
More than 8 hours (a charge) |
|||||||||||||||||||||||
|
| ||||||||||||||||||||||||
