contactless smart card reader RFID card encoder
Product description
CF-RH320 series desktop readers are smart modules without touching based on international standard agreement ISO14443A/B,ISO15693
CF-RH320 are equipped with high capability chip, processor, security and electric monitor. The reader can communicate with PC by means of interface.
CF-RH320 are of high capability, anti-jamming, small size and good quality, which brings more convenience.
Product model explanation
Model |
standard |
interface |
color |
CF-RH321 |
IS014443A |
U(USB)/R(RS232) |
B(black)/W(white) |
CF-RH322 |
IS014443A/B |
U(USB)/R(RS232) |
B(black)/W(white) |
CF-RH323 |
ISO15693 |
U(USB)/R(RS232) |
B(black)/W(white) |
CF-RH324 |
ISO/IEC14443A/B,ISO15693 |
U(USB)/R(RS232) |
B(black)/W(wh |
Name |
HF Reader&write |
Dimension |
104x68x10mm |
Standard |
ISO14443A/ISO15693 |
Support |
M1 S70; M1 UltraLight; M1 S50,I-code2 |
Frequency |
13.56MHz |
speed |
106kbit/s |
Baud Rate |
9600 bit/s |
Power Supply |
+5V DC |
Consumed Current |
< 80Ma |
Operating Distance |
50--70mm |
Interface |
USB/RS232 |
Status Indication |
1pcs LED;1pcd buzzer |
Service Temperature |
-10°C ~ +70°C |
Store Temperature |
-20°C ~ +80°C |
Product application
Widely used in access control, attendance, conference attendance, medical insurance, hotels, highways, petrol stations, parking, public transportation, such as toll collection system.
Other support
1.The reader come with completed English SDK,demo software, user manual and source code, and these documents will help you develop the software for your application
2.When you buy our reader, we can provide free card tor testing
More information about this product , please visit this link:
1. Are you manufacturer?
Yes, we are 10 years professional RFID hardware manufacturer.
2. What is your mainly product?
Our products mainly include RFID reader, RFID tag, RFID module and antennas,
include 125KHz , 13.56MHz and 860-960MHz three frequency.
3. What is your advantage?
We are professional RFID hardware solution provider,
we have strong technical team can provide after sale technical support online,
also can provide customized service.
4. How to place order to Chafon?
You can place order to us through Alibaba trade assurance order online.
We also can accept payment by TT,Western Union or Paypal.
