0~90cm long range 125khz rs485 em4100 reader
Product Description
CF-RL150 series It's a high performance, lower price long range 125 KHZ RFID reader, reader distance up to 90cm, widely used for RFID Radio Frequency Identification system and project, such as Automated parking management system, Personal identification, Access controller, Production Access control, etc.
Product model explanation
Model |
output Byte |
output format |
support |
CF-RL151 |
3 |
Weigand 26 |
EM and compatible card |
| CF-RL152 | 4 |
RS485 |
EM and compatible card |
CF-RL153 |
4 |
RS232 |
EM and compatible card |
Capability specifications
1.Working signal format: Weigand 26, ABA, RS232
2.Reader Card speed: <0. 2/S
3.Sensing distance: 0-90CM *
4.Read card frequency: 125KHz
5.Temperature Operating: -25o C-75o C
6.Operating Humidity: 10-90%
7.Inside Antenna: Have
8.Embedded speakers: Buzzer
9.Working voltage: DC 12V
10.Working Current: 70mA
11.Networking way: Wiegand 26bits/ABA standard format output
12.Read range: 70~90cm
13.Device color: Black
14.Size: (L)235mm, (W)240mm, (H)35mm
15.Packing Box Size: 28. 5*26. 5*6. 5 inch
16.Unit Device Weight: 1. 5kg; Unit Packing Box Weight: 1. 8kg.
Standard Accessories
1.Long ranger reader machine 1pc
2.Certified sheet 1
3.Warranty Card 1
4.Instruction Sheet and connect sheet 1
5.Testing cards
1. Are you manufacturer?
2. What is your mainly products?
Our products mainly include RFID reader, RFID tag, RFID module and antennas,
3. What is your advantage?
We are professional RFID hardware solution provider,
we have strong technical team can provide after sale technical support online,
also can provide customized service.
4. How to place order to Chafon?
You can place order to us through Alibaba trade assurance order online.
We also can accept payment by TT,Western Union or Paypal.
