Low Cost LF 134.2khz RFID Animal Reader
| Product Details: | |
| Our website is .The DL710PLUS product is an industry-level handheld terminal developed, designed, and produced based on features of different industries by our company. The DL710PLUS series adopt ergonomic design and is compact and flexible, shock-proof, and drop-proof. The DL710PLUS series can work in the standby mode for a long time. In addition, the DL710PLUS series adopt the dual power supply mode and support the conversation function, is perfect for Applicable Apparel industry, fast moving consumer goods (FMCG), retail, and supply chain industries Logistics industry, Hospital, government, mobile office, asset inventory and other RFID applications. | |
| RFID | |
| Type | LF&HF Handheld Reader DL710PLUS |
| Operating Frequency | LF(Low Frequency) 125 KHz or HF(High Frequency) - 13.56MHz |
| Protocol | ·LF - EM4001 & EM4100 & TK4100 |
| ·HF - ISO15693 & ISO14443 | |
| Reading Range | 10cm maximum |
| SDK | Free SDK provided attached to the Reader |
| System features | |
| Operating system | Microsoft Windows CE 5.0 OS (Multi-lingual) |
| Processor | SAMSUNG S3C2451 (533 MHz) |
| Memory | |
| Memory | 128 MB SDRAM |
| Flash memory | 128/256/512 MB (standard configuration: 128 MB) |
| Extension | Micro SD/TF slot (a maximum of 16 GB) |
| Barcode Scanning Parameters | |
| Scanning engine type | One-dimension laser scanner |
| Scanning speed | 100±20 per second (bidirectional) |
| Scanning distance | 60–650 mm |
| Scanning angle | 54±5 degree |
| Resolution | 0.127–1.00 mm |
| Readable bar codes | UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13, Bookland EAN, Code 128, UCC/EAN-128, Code 39, Trioptic Code 39, Code 39 Full ASCII, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, GS1 DataBar 14, GS1 DataBar Limited, GS1 DataBar Expanded |
| Audio, Slots, and Ports | |
| USB Ports | 1 USB Interface |
| Slots(Extension) | 1 Micro SD/TF slot |
| Input/Output devices | |
| Input devices | Soft keyboard, Hard keyboard, Scanning start key |
| Output devices | 3.2 in. TFT-LCD QVGA , (240 x 320) color touch screen |
| Communication features | |
| Wi-Fi WLAN(standard configuration) | 802.11b/g |
| Bluetooth(standard configuration) | Bluetooth V2.1+EDR |
| Wide-area wireless network (extension) | Provides a GSM/GPRS wireless communication module and supports GSM/GPRS Class10 and GSM0710 multiplexing. |
| Camera(extension) | Camera with 2 million/3 million pixels and fill light |
| GPS(extension) | Integrated |
| Product specifications | |
| Dimensions | 150 x 70 x 25 mm (w x d x h) |
| Weight | 200g |
| Energy Efficiency | |
| Master battery | 3.7 V 2800 mAh rechargeable lithium battery |
| Working hours | 8 or above (depending on the actual environment) |
| Charging time. | 3.5 hours |
| Slave battery | 150 mAh, providing power for six hours |
| Environment Requirement | |
| International Protection | IP54 |
| Operating Temp | -15°C to 50°C |
| Storage Temp | -20°C to 60°C |
| Humidity | 5% to 95% Non-condensing |
| Endurable height for dropping | Endure multiple drops to a smooth concrete floor from a height of 4 inches (1.2 m). |
More Prictures for Low Cost LF 134.2khz RFID Animal Reader
