Specifications
Ribbed Weld MeshCE&ISO9001&SGS
Wire diameter: 4-16mm
Width:1m-3m
Lengt:2m-12m
Ribbed Weld Mesh
(CE&ISO9001 certificates)
Ribbed Weld Mesh also named welded steel bar panels, concrete mesh, construction mesh.
Ribbed weld mesh is a new construction material of reinforced welded mesh.
1. Detailed specification
Material: Low carton steel wire, stainless steel wire, ribbed bars
Wire diameter: from 4mm-10mm.
Panels opening: the Horizontal from 50mm to 200mm, the Vertical from 25mm to 500mm.
Panel length: 1.0m -6m.
Panel width: 1M- 3.0m.
Weaving: Galvanizing before or after welding
Category: Hot-dipped, electrical galvanizing, PVC coating, plastic soaked
Specification of Ribbed Weld Mesh | ||||
Wire Diameter(mm) |
Mesh (mm) |
Panel Length(m) |
Panel Width(m) |
Material |
4mm-16mm |
75mm x75mm 100mmx 100mm 150mm x150mm 200mm x200mm |
No more than 12m |
No more than 3.4m |
Hot rolled ribbed bars, Cold plain ribbed bars, Cold rolled ribbed bars |
Note: |
Diameter, mesh, width, length can be according to the customers' requirement. |
|||
2. Uses:
It is widely used in reinforced concrete structures of multistory and high buildings, airport runnels, concrete pipes, bridge, warehouse and sewage treatment tanks.
3. Features:
Smooth and trim mesh surface, sold and uniform structure and superior integral performance, it won’t loosen even subject to local cutting or pressure, it has the characteristics of corrosion-resisting and oxidation-resisting.
4. Packing:
pallet, Wooden Box. Special packing can be arranged upon request.
5. Pictures for reference
