Ribbed Welded Mesh

Specifications

Ribbed Welded Mesh
CE&ISO9001&SGS
Wire diameter: 4-16mm
Width:1m-3m
Lengt:2m-12m

Ribbed Welded Mesh

(CE&ISO9001 certificates)



Ribbed Welded Mesh also named welded steel bar panels, concrete mesh, construction mesh.



Ribbed welded mesh is a new construction material of reinforced welded mesh.



1. Detailed specification



Material: Low carton steel wire, stainless steel wire, ribbed bars

Wire diameter: from 4mm-10mm.

Panels opening: the Horizontal from 50mm to 200mm, the Vertical from 25mm to 500mm.

Panel length: 1.0m -6m.

Panel width: 1M- 3.0m.

Weaving: Galvanizing before or after welding

Category: Hot-dipped, electrical galvanizing, PVC coating, plastic soaked



Specification of Ribbed Welded Mesh
Wire Diameter(mm)	Mesh (mm)	Panel Length(m)	Panel Width(m)	Material
4mm-16mm	75mm x75mm 100mmx 100mm 150mm x150mm 200mm x200mm	No more than 12m	No more than 3.4m	Hot rolled ribbed bars, Cold plain ribbed bars, Cold rolled ribbed bars
Note:	Diameter, mesh, width, length can be according to the customers' requirement.



2. Uses:

It is widely used in reinforced concrete structures of multistory and high buildings, airport runnels, concrete pipes, bridge, warehouse and sewage treatment tanks.



3. Features:

Smooth and trim mesh surface, sold and uniform structure and superior integral performance, it won’t loosen even subject to local cutting or pressure, it has the characteristics of corrosion-resisting and oxidation-resisting.



4. Packing:

pallet, Wooden Box. Special packing can be arranged upon request.



5. Pictures for reference
