Home > Products > hydraulic automatic block making machine > Best Selling Products !! fly ash brick making machine in india price
Best Selling Products !! fly ash brick making machine in india price
- 200 Set / Sets per Month
- QINGDAO
- T/T
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Hollow Block Making Machine | Brick Raw Material: | Concrete |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 10000pcs/day | Place of Origin: | Shandong, China | Brand Name: | Dongyue |
Model Number: | QT10-15 | Voltage: | 380V/220V/440V | Power: | 27KW |
Dimension(L*W*H): | 2440*2000*2600mm | Certification: | CE/SGS/ISO9001 | Warranty: | 1 YEAR |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.germany technology2.Produce hollow/solid bricks
3.Passed ISO9001 CE SGS
4.20 years manufacturing experience
Best Selling Products !! fly ash brick making machine in india price
Automatic concrete brick paver machine mainly advantage:
Till now, our automatic block making machine is available with QT4-15B series, QT4-15C series, QT6-15 series, QT6-15B series, QT8-15 series, and QT10-15 series. It has been certified by CE, SGS, TUV, and the like. Our machine has been approved by Bureau Veritas, TUV CERT.
1.QT Series Concrete / Fly ash Brick Machine Features
1. Mainframe
The automatic block making machine applies the high-strength structural steel and special welding technique for its mainframe. The firmness of the mainframe allows the whole machine to come with good rigidity and vibration resistance.
2. Guide Pillar
The guide pillar of this machine applies the ultrastrong special steel. By virtue of the chromate plated treatment, it perfectly resists torsion and abrasion. Additionally, the four guide pillars together with the ultra-long guide bearing make the pressure head and mould move accurately. This moving system adopts the special device that is good for lubrication, thus avoiding abrasion.
3. Material System
The crane of the material machine is controlled by the hydraulic system. That its hopper is connected to the crane by the rubber spring, can offer favourable damping effect while preventing the vibration compaction of the remained materials. In the system, the hopper is equipped with a door which can help realize the uniform material distribution.
4. Material Distributing System
In this system, the material storage and distribution are independent from each other. The material receiving in the material box is accurately controlled. Under the function of the powerful centrifugal force, the material is speedily and evenly distributed.
5. Vibration System
For the vibration system, our equipment employs the separate type coupling vibration technology, which can enlarge the effective vibration area by 2 times. This technology not only helps improve the product quality and output, but also it can prolong the mould service life with effect. In addition, the vibration cabinet of hanging type structure can bear intensive vibration, and no damage or breakage appears. Meanwhile, the vibrating shaft rotates eccentrically and synchronously to generate vertical exciting force, which can ensure the optimal material distribution and block molding effect.
6. PLC Control System
Technical parameters including flow, pressure, etc., can be set via the touch screen. All the electric elements are imported famous brands, such as Mitsubishi, Omron, SIEMENS, etc. Therefore, the control system is reliable in performance. The failure rate is extremely low. In the system, there are three controlling units, all of which are described as below:
a. The full-automatic controlling system for the material mixing;
b. Automatic controlling system used for molding machine, conveyor, and so on;
c. Stacker controlling system
7. Multifunction
When equipped with different moulds, this automatic block making machine can make any size concrete products, for instance, perforated bricks, hollow blocks, etc. If installed with the material device, it also can produce the color bricks.
2. Detals instroducing of QT series Automatic concrete / fly ash brick machine
A. QT4-15B automatic concrete brick machine
(1). Main Technical Parameter
Host machine demension: | 2800*1800*2700mm |
Rated pressure: | 40Mpa |
Main vibration form: | platform vibration and hyraulic pressure |
Vibration frequency | 4600(r/min) |
Pallet size | 1050*550*25mm |
Molding cycle: | 15-25s |
Power | 25KW |
Weight of Machine | 7.5T |
Production capacity | 10m³/h |
(2).Production capacity
Size | Quantity | Shaping Cycle | Per hour | |
Hollow block | 400*200*200mm | 4 | 15-25s | 750pcs |
Hollow block | 400*100*200mm | 8 | 15-25s | 1500pcs |
fly ash brick | 230*110*76mm | 24 | 15-25s | 4000pcs |
color brick | 200*100*60mm | 16 | 15-25s | 2800pcs |
B.QT6-15 automatic concrete brick machine
(1). Main Technical Parameter
Host machine demension: | 2850*2200*2850mm |
Rated pressure: | 60Mpa |
Main vibration form: | platform vibration and hyraulic pressure |
Vibration frequency | 4600(r/min) |
Pallet size | 940*830*25mm |
Molding cycle: | 15-25s |
Power | 35KW |
Weight of Machine | 11.5T |
Production capacity | 20m³/h |
(2).Production capacity
Size | Quantity | Shaping Cycle | Per hour | |
Hollow block | 400*200*200mm | 6 | 15-25s | 1100pcs |
Hollow brlock | 400*100*200mm | 12 | 15-25s | 2100pcs |
fly ash brick | 230*110*76mm | 30 | 15-25s | 5000pcs |
color brick | 200*100*60mm | 24 | 15-25s | 4000pcs |
C.QT10-15 automatic concrete brick machine
(1). Main Technical Parameter
Host machine demension: | 3500*2200*2850mm |
Rated pressure: | 100Mpa |
Main vibration form: | platform vibration and hyraulic pressure |
Vibration frequency | 4600(r/min) |
Pallet size | 1300*900*30mm |
Molding cycle: | 15-25s |
Power | 45KW |
Weight of Machine | 14T |
Production capacity | 30m³/h |
(2).Production capacity
Size | Quantity | Shaping Cycle | Per hour | |
Hollow block | 400*200*200mm | 10 | 15-25s | 1100pcs |
Hollow brlock | 400*100*200mm | 14 | 15-25s | 2100pcs |
fly ash brick | 230*110*76mm | 42 | 15-25s | 7500pcs |
color brick | 200*100*60mm | 35 | 15-25s | 6000pcs |
D.Small / Manaul / Mobile / Egg Laying Concrete / Fly Ash Brick Machine
E.Simple / Small Concrete / Cement Concrete / Fly Ash Brick Machine
Our company is the biggest manufacture for AAC block machine / Fly ash aerated concrete block machine / Concrete Block Making Machine/ baking free block making machine in China, Our company offers complete production lines for premium building components such as the autoclaved sand-lime brick, autoclaved aerated concrete block, and autoclaved aerated concrete / autoclaved lightweight concrete panel.
we has set up office in India,Vietnam, Indonesia,Russia and we can supply the best technology support and service for customers.
We can supply our customer for designning, production, installation, commissioning, training and good after-sale service. Capacity: from 50000 cubic meter to 300,000 cubic meters per year.
We also produce kinds of concrete /cement block making machine, including automatic brick making machine, semi-automatic brick making machine, manual brick making mahcine, hollow / solid brick making machine etc brick making machine.
