Specifications
circulating fluidized bed boiler1.ASGM ,ISO certificate
2.30years manufacturing experience
3.
ciculating fluidized bed boiler
product features;
1. many kinds of fuel shall be applicable ,including high quality coal as well as inferior coal with low volatile and high ash.
2. because of high combustion efficiency and full gas and solid state mixture, uncompleted burning large particles shall loop back to the furnace.
3.the boiler shall realize efficient desulfurating, low temperature combustion, and low discharge of nitrogen oxide.
4.with a high speed,the load can be adjusted in a wide range.
5.by comparison with pulverized coal fired industrial boiler, the fuel preprocessing systerm is simple ,which is easy to implement comprehensive utilization of ash.
Main performance parameters of circulating fluidized bed boiler
boiler type LG-35/3.82-M LG-75/3.82-M LG-130/5.3-M
items
rated output t/h 35 75 130
rated working pressure MPA 3.82 3.82 5.3
rated steam temperature 450 450 450
feedwater temperature 105 130 150
combustion mode circulating fluidized bed combustion
applicable fuel bitminous coal 80 stone coal petroleum coke
anthracite/lean coal 20 bituminous coal
lignite/gangue/slime
petroleum coke
fuel particle size requirement no more than10mm 8mm 10mm
limestone particle size requirement 2mm 2mm 2mm
drum centerline elevation 25000mm 28300mm 33000mm
boiler proper highest point elevation 26750mm 33950mm 54270mm
main products pictures:
DONGYUE MACHINERY GROUP WELOCME YOU TO VISIT AND TALK BUSINESS.
