Specifications
hot water boiler1.ASGM/CE certificate
2.30 years experience
3.horizontal cyclone reburning chamber
SZL series packaged hot water boiler
product features:
1. the boiler shall be equipment with horizontal cyclone reburning chamber of an original creation in the home market,featuring the obvious effect of increasing combustion effciency and decreasing smoke discharge density whichis lesser than 80mg/NM3,and at the same time,cleaning fume,of which the blackness is less than I lingemann,meeting the requirements' of grade i enviroemntal protection area.
2. the boiler thermal efficiency' is high,every kind of which shall exceed 5 per cent of national standard.
3.the water tube boilerfeatures the following advantages: rational structure,safe operation,and long boiler life.
4.the air register shall use cone seal structure of machining equipment,and the uniform blast duct structure shall be applied to air distribute device of wind chamber,which is enviroment patent technology of state.
5.many kinds of fuel shall be applicable ,including II and III coal.
6.because of compact structure,small floor area,and monolayer arrangement of the boiler room,the cost of the boiler house and installation shall be economized.
7.the boiler was awarded the following titles: first class products of mechanical and electrical department ,enviromental products trusted by the national users,exxellent energy-saving products promoted by state,excellent energy-saving products of shandong province.
8. according to the customers' requirements, the layering burn device and other energy saving equipments, implemented in state,shall be matched.
Main performance parameters of SZL series pakaged hot water boiler.
Main Specifications of SZL Series Package Hot-water Boiler | ||||||||
boiler model items | QxG 0.35-0.7 /95/70-AII | SzG 0.35-0.7 /95/70-AII | SZL 0.7-0.7 /95/70-AII 2 | SZL 1.4-0.7 /95/70-AII 2 | SZL 2.8-0.7 /95/70-AII 2 | SZL 4.2-0.7 /95/70-AII 2 | SZL 4.2-1.0/ 115/70-AII | SZL 5.6-0.7 /95/70-AIII |
rated heat power MW | 0.35 | 0.35 | 0.7 | 1.4 | 2.8 | 4.2 | 4.2 | 5.6 |
rated working pressure Mpa | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 1.0 | 0.7 |
output water temperature °C | 90 | 95 | 95 | 95 | 95 | 95 | 115 | 95 |
return water tenperature °C | 70 | 70 | 70 | 70 | 70 | 70 | 70 | 70 |
combustion method | back-firing solid grate of double layer | back-firing solid grate of double layer | the chain link level burns | the chain link level burns | the chain link level burns | the chain link level burns | the chain link level burns | the chain link level burns |
applicable coal (bituminous coal) | AII , AIII | AII , AIII | AII , AIII | AII , AIII | AII , AIII | AII , AIII | AII , AIII | AII , AIII |
effective area of grafe m 2 | 1.0 | 0.93 | 1.29 | 3 | 4.6 | 7.23 | 7.23 | 8.6 |
the body heating surface m 2 | 17.2 | 22.59 | 33.39 | 69.4 | 115.3 | 157.6 | 137.6 | 196.9 |
economizer heating surface m 2 | / | / | / | / | / | / | 55.5 | / |
the coal consumption at full load operation ( Kg/h ) | 65 | 87 | 156 | 302 | 596 | 897 | 974 | 1105 |
exit gas temperature °C | 195 | 160 | 195 | 190 | 190 | 190 | 160 | 170 |
effluent concentration of the smoke dust (mg/nm 3 ) | <80 | <80 | <80 | <80 | <80 | <80 | <80 | <80 |
smoke blackness (Ringelmann level) | ||||||||
approved thermal effciency % | 74 | 78 | 75.19 | 78.8 | 80.4 | 81.56 | 78.18* | 81.5 |
heatingable area m 2 | 3000 | 3000 | 6000 | 12000 | 24000 | 36000 | 36000 | 48000 |
the biggest transportatio size (long x width x high) mm | 2620x 1650x 1780 | 2750x 1840x 2970 | 4080x 2150x 2862 | 5960 x2690x 3462 | 6510x 3130x 3462 | 7830x 3480x 3462 | 7170x 3270x 3612 | 8820x 3480x 3462 |
dimensions of biggest part for transportation t | 4.5 | 6 | 15 | 20 | 28 | 36 | 36 | 45 |
overall dimensions of installed boiler ( length x width x height) mm | 3000x 2000x 2000 | 3000x 1840x 3000 | 5355x 3550x 3262 | 6495x 4963x 3862 | 7045x 5197x 3862 | 8365x 5332x 3862 | 12437x 3795x 4012 | 9380x 5332x 3862 |
Notes:The coal consumption at full load operation calculates to bituminous coal class II( dw=21320KJ/kg )The items used* above refer to designed efficiency | ||||||||
SZL series packaged hot water boiler.
welcome to visite dongyure machinery group at your convenient time!
