WNS,SZS Series Oil/Gas Fired Steam/hot Water Boiler

Dongyue Machinery Group Co., Ltd.
WNS,SZS Series Oil/Gas Fired Steam/hot Water Boiler thumbnail-1
WNS,SZS Series Oil/Gas Fired Steam/hot Water Boiler photo-1
US$ 100,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Natural Circulation
Usage Industrial
Structure Fire Tube
Pressure High Pressure
Style Horizontal
Fuel Oil-fired
Place of Origin Shandong, China
Brand Name dongyue
Model Number WNS,SZS Series
Output Steam
Certification ISO/ASM
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Oil/Gas fired steam Boiler
1.ISO/ASM certificate
2.high quality and good aftersales service
3.20years exporting experience







Product Features of WNS,SZS Series Oil(Gas)-fired  steam Boiler:







 1,It is of the following features,such as full-auto-running,safety and reliability,varuous of control and protection device makes steam pressure,water temperature and combustion system are all automatic control with easily operate,save labour and raise the serviceability.Hot water boiler have program-controlled,temperature-controlled and time-controlled.



 2,Equipped selectiy with import burner,the yuel can be full burned with greatly save energy effect.It can conform with the demanding regions.



3,Full-closed structure of the boiler and with features of smalless,noiseless,no pollution,good-looking and cleaniness.



4,Compact structure,small area occupation and easy to be installed.



CWNS Series Full-automatic Oil(Gas)-fired Generally Press Hot-water Boiler

boiler model

items

CWN

0.35-95/70-Y(Q)

CNW

0.7-95/70-Y(Q)

CNW

1.4-9.5/70-Y(Q)

rated heat power MW

0.35

0.7

1.4

rated working pressure Mpa

normal atmospheric pressure

normal atmospheric pressure

normal atmospheric pressure

rated return water temperature °C

70

70

70

rated outpput water temperature °C

95

95

95

heating surface area m 2

17.5

37

79

designed fuel

Oil,Gas

Oil,Gas

Oil,Gas

designed effciency %

86.63

90

90

combustion consumption ( kg/h )

( 32.53 )

( 65 )

( 125 )

burner

import

import

import

The boiler may be use heavy oil,residual oil,gas and natural gas. It must be noted when contrast is concluded.

CWNS Series Full-automatic Oil(Gas)-fired Generally Press Hot-water Boiler

boiler model

items

WNS 0.35-0.7/95/70-Y(Q)

WNS 0.7-0.7/97/70-Y(Q)

WNS 1.4-0.7/97/70-Y(Q)

WNS 2.8-0.7/97/70-Y(Q)

WNS 4.2-0.7/97/70-Y(Q)

SZS 7-1.0/97/70-Y(Q)

rated heat power MW

0.35

0.7

1.4

2.8

4.2

7

rated working pressure Mpa

0.7

0.7

0.7

0.7

0.7

1.0

rated outpput water temperature °C

95

95

95

95

95

95

rated return water temperature °C

70

70

70

70

70

70

heating surface area m 2

17.5

29.08

59.13

111.2

166.7

377.5

designed fuel

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

designed effciency %

88.2

88.63

88.8

89.3

89.6

90.6

combustion consumption ( kg/h )

33.9

66.3

127

252

377

621

burner

import

import

import

import

import

import

The boiler may be use heavy oil,residual oil,gas and natural gas. It must be noted when contrast is concluded.


WNS/LNS Series Full-automatic Oil(Gas)-fired Steam Boiler

boiler model

items

WNS

0.5-1.0-Y(Q)

WNS

1-1.0-Y(Q)

WNS

2-1.0-Y(Q)

WNS

2-1.25-

Y(Q)

WNS

4-1.25- Y(Q)

WNS

6-1.25-

Y(Q)

WNS

0.2-0.7-

Y(Q)

WNS

0.35-0.7-

Y(Q)

rated steam capaciry t/h

0.5

1

2

2

4

6

0.2

0.35

rated working pressure Mpa

1.0

1.0

1.0

1.25

1.25

1.25

0.7

0.7

feed water temperature °C

20

20

20

20

20

20

20

20

steam temperature °C

184

184

184

194

194

194

170

170

the boiler heating surface m 2

14.3

28.08

59.13

58.3

105

166.7

6.22

9.15

design fuel

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

light diesel oil

designed effciency %

82.7

84.77

86

90

88

88

85

85

combustion consumption ( kg/h )

37.6

73.4

143

143

283

424

14.1

23

burn

import

import

import

import

import

import

import

import

The boiler may be use heavy oil,residual oil,gas and natural gas. It must be noted when contrast is concluded.



WNS/LNS Series Full-automatic Oil(Gas)-fired Steam Boiler

boiler model

items

SZS

2-1.25-Y(Q)

SZS

4-1.25-Y(Q)

SZS

6-1.25-Y(Q)

SZS

10-1.25-Y(Q)

SZS

20-1.25-Y(Q)

rated steam capaciry t/h

2

4

6

10

20

rated working pressure Mpa

1.25

1.25

1.25

1.25

1.25

feed water temperature °C

20

20

20

105

105

steam temperature °C

194

194

194

194

194

the boiler heating surface m 2

68.8

125.3

165.1

210

435.2

the economizer heating surface m 2

18.48

37

49.28

144

236

design fuel

coke gas

coke gas

coke gas

coke gas

coke gas

designed effciency %

88.99

90.35

89.67

90.24

89.17

combustion consumption ( kg/h )

347.5

684.5

1034.57

1474.4

2984.4

burn

import

import

import

import

import

The boiler may be use heavy oil,residual oil,gas and natural gas. It must be noted when contrast is concluded.



 WNS,SZS Series Oil/Gas fired steam/hot water Boiler
