Description:
It is made from synthetic latex, plants fiber and filling material. The production is used for position of lubrication system, which has the property of good compressibility and coefficient of resilience, in addition, the inside of gasket can properly swell to meet oil, that make up of the shortcoming that procession machining precision is not enough, which affected self-sealing.
Vulcanized Non-asbestos latex sheet, it is by vulcanizing, it has smooth face and high density,it can be cut into all kinds of gasket directly.
APPLICATION & PARAMETER:
Used in Automobile, farm machinery, motors, engineering etc. It can be used in oil system and water supply system at temperature 150
Item |
Non-asbestos latex paper |
Vulcanized Non-asbestos latex sheet |
Density g/cm3 |
0.9~1.1 |
1.2~1.4 |
Tensile strength |
12.7 |
|
Compressibility |
15 |
|
Recovery |
45 |
|
Stress relaxation |
35 |
|
Weight increase (in oil) |
35 |
|
Thickness increase (in oil) |
15 |
|
Normal color: Grey, Black, White
THICKNESS TOLERANCE:
Item |
Tolerance |
In same sheet |
Thickness |
|
mm |
0.5 |
0.05 |
0.06 |
0.6-0.8 |
0.06 |
0.08 |
1-2 |
0.08 |
0.08 |
Item |
Tolerance |
In same sheet |
Thickness |
|
mm |
0.5 |
0.05 |
0.06 |
0.6-0.8 |
0.06 |
0.08 |
1-2 |
0.08 |
0.08 |
DIMENSIONS:
Width: 500mm; 1000mm
Length: 500mm; 1000mm; 1200; 1300mm
Thickness: 0.6~2.0mm
