Specifications
Metal wire weave test sieve1.ISO3310-1:1990 R20/3,R20,R40/3 series
2.Mesh size: 2.36-0.02mm
3.Resistance of acid & alkali
Test sieves of metal wire cloth/Tongxin Taylor standard screen
1. Brief introduction:
The basic hole dimensions of the metal wire braided test sieve is 2.36 mm - 0.02 mm, accord with international international standard ISO3310 -90R20/3, the R20, R40/3 series, the screen cloth is made of stainless steel SS304 namely 0Cr18Ni9 and brass. To assurance quality, our company uses the tool microscope, projectors, standard sand, and other special inspection equipment and special check tools to make sure the quality-the mesh accuracy of the test sieve.
2. The main technical parameters
Item |
Description |
Material |
Stainless Steel304(0Cr18Ni9), H80 Brass |
Production Technology |
Weaving |
Production Standard |
ISO3310-1:1990 R20/3,R20,R40/3 series and BSI,ASTM,TYLER,JIS,DIN standard |
Diameter(mm) |
75/ 100/ 127/ 200/ 203/ 300/ 400/ 600 |
Frame Thickness |
0.6-0.7 mm |
Mesh Size range |
2.36mm-0.02mm |
Application |
widely used in abrasive, building materials, chemical, pharmaceutical, metallurgy industries, etc. |
We can provide different sizes of test sieves according to the customers' order.
3. The matching up standard test sieve machines:
