Specifications
1.have the stocks, the delivery time is 3 working days2.Small noise, light weight,manual work is delicate
3.ISO:9001:2008
1.Vibration style:motor vibration
2.Function:Used for solid and liquid particle size analysis
3.Main Features:
(1)Ordinary standard sieve machine can be screening to 325 mesh(0.045mm)
(2)Small noise and light weight
(3)Platform operation ,needn't fixed,mobile and installation is convenient
(4)High efficiency, compact design and durable, and any powder and liquid can be screened.
(5 ISO:9001:2008 and CE certification
4.Application industry:
Widely used in food, medicine, chemicals, abrasives, pigments, mining, metallurgy,
geology, ceramics, and national defense industry
5. Application field:
It is used in the scientific research units, laboratories,testing labs, production and
control to test, screen, grade, analyse the particles, analyse debris content of solid,
powder, slurry feed materials and so on.
6.Technical Parameters:
| Name | Parameters | Units |
| Putting sieve layers | 1-7(Including the sieve bottom) | layer |
Putting sieve diameter |
200/150/100/75 or customized |
mm |
| Screening granularity | 0.045-3 | mm |
| Screen mesh | 325 | mesh |
| Motor Power | 0.12(0.15 general electric) | kw |
| Noise | Less than50 | db |
| Amplitude | 0-3 | mm |
| Vibration frequency | 1400 | times/min |
| Size | 350x380x300+N*50 | L*W*H |
| Voltage | 220 | V |
| Frequency | 50 | HZ |
| Total Weight | 35 | KG |
