Specifications
Polished inside and outside the 400 present, Gmp compliance standards, anti-corrosion, easy operation, strong adaptability
Model |
Layers |
Filtering area(M2) |
Filter Material size(mm) |
Microporous membrane filter(μm) |
Filtration pressure(Mpa) |
Flow(T/h) |
Carbon deposits(kg) |
Motor Power(KW) |
CT-Φ300 |
5 |
0.7 |
Φ310 |
0.22-3 |
0.2-0.6 |
4 |
3 |
0.75 |
CT-Φ300 |
10 |
1.4 |
Φ310 |
0.22-3 |
0.2-0.6 |
8 |
6 |
1.1 |
CT-Φ300 |
15 |
2.1 |
Φ310 |
0.22-3 |
0.2-0.6 |
12 |
9 |
1.5 |
CT-Φ300 |
20 |
2.8 |
Φ310 |
0.22-3 |
0.2-0.6 |
16 |
12 |
2.2 |
The machine filter filter by multi-layer overlapping panels and flange ring formed by the computer stencil hole punch, hole density of small uniform, which ensures the filter on each plate pressure filter even the filtering accuracy of Birth , the machine chamber shell and chassis form a closed cavity, liquid pressure into the barrel through the liquid outer flange ring over the top hole into the body cavity, through the filter mesh panels, and more from the middle of a small flange holes out, passing the liquid discharge outlet. The machine can use PP membrane filter, enhanced membrane, filter paper, filter cloth, special machine filters the film, can be qualified according to the user selected filter. Traffic flow, speed, save more than activated carbon, filtration area, high efficiency and easy operation. CT-500-CT800 filter removable fixation within the root 3-6 (quick type), CT-300, CT-400 filter with center screw compression (quick nut used in conjunction with the Arch gland ).
