Competitive Rubber Conveyor Belt Price From China Manufacturer
1. Machine introduction of Rubber Conveyor Belt Price
Belt conveyor has the advantage of big throughput, simple structure and easy maintenance, standardization of components etc. which is widely used in the mining, metallurgy, coal department, etc. for conveying loose material or final goods. According to the transmission technology requirements, it can transport signally can also transport with more machines or compose with other equipment as level or tilt conveying system. In order to meet the different needs of lines.The belt conveyor can use in environmental temperature -20° to +40°. The conveyed materials’ temperature is below 50 degrees.
2. Machine features of Rubber Conveyor Belt Price
1) long life ( reach 10 years)
2) light weight and small volume (reduce 50%)
3) compact construction and small floor space (reduce above 50%)
4) high precision, high loading capacity with hard mask gear(2 to 3 times more than soft mask gear)
5) able to connect with others portable belt conveyor to extend the length of transporting distance
6) able to adjust the degree of slope in order to achieve preferable height of unloading point via
adjusting the lifting frame.
3. Technical parameters of Rubber Conveyor Belt Price
Belt width (mm) |
Length (m) / Power (KW) |
Conveying Speed (m/s) |
Capacity (t/h) |
||
400 |
≤12/2.2 |
12-20/2.2-4 |
20-25/4-7.5 |
1-2.0 |
30-60 |
500 |
≤12/3 |
12-20/3-5.5 |
20-30/5.5-7.5 |
1-2.0 |
40-80 |
600 |
≤12/4 |
12-20/4-5.5 |
20-30/5.5-11 |
1-2.0 |
80-120 |
800 |
≤10/4 |
10-15/4-5.5 |
15-30/5.5-15 |
1-2.0 |
120-200 |
1000 |
≤10/5.5 |
10-20/5.5-11 |
20-40/11-22 |
1-2.0 |
200-320 |
1200 |
≤10/7.5 |
10-20/7.7-15 |
20-40/15-30 |
1-2.0 |
300-480 |
4. Contact information of Rubber Conveyor Belt Price
If you need further information, please contact us freely, we will do our best to cooperate with you.
