Waste Paper Egg Tray Making Machine Price
- 300 Set / Sets per Month
- Qingdao or as customers' request
- T/T Credit Card PayPal
- Best quality factory price jumbo roll paper machine
- Toilet Paper Cutter/Kitchen Towel Cutting Machine Price with High Performance
- N Fold Hand Paper Towel Dispenser Packaging Machinery Manufacturer
- Automatic paper recycling machine for produce craft paper from www.frdpapermachine.com
- Durable and sturdy spiral paper tube machine
- Durable and sturdy corner protectors
Product Details
Condition: | New | Product Type: | Paper Cup Machine | Processing Type: | Pulp Molding Machine |
Place of Origin: | Henan, China | Brand Name: | HENTO | Model Number: | HTO-ZBM100 |
Voltage: | 380v | Power(W): | 87.35KW | Dimension(L*W*H): | 30mX8mX4.5m |
Weight: | Unconfirmed | Certification: | CE | Warranty: | 2 years |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Waste Paper Egg Tray Making Machine Price
1.Brief Introduction of the Egg Tray Making Machine Price
Machine for make paper egg tray,egg tray making machine,egg tray machine,paper tray machine.pulp moulding machine.
Egg tray forming machine is a kind of machine which absorbs paper pulp-the raw material, on the surface of mould by vacuum to get various shape and ratio of wet and dry by regulating time. After such working procedure as transferring moulds, releasing moulds to complete paper tray production. Our forming machines adopt advanced PLC programmable controller; selecting of high quality electronic devices and pneumatic components; using stainless steel pulp barrels with high performance and long service life.
various types and output of egg tray making machines can be supplied by our company ,
such as 800-1000pcs per hour ,2000pcs per hour,3000pcs per hour ,4000pcs per hour ,and so on .
2. Technical Parameters and compositon parts of the Egg Tray Making Machine Price
1. Pulping system
Pulper, 1.0M3,15kw;
vibration screen, 0.9M2,3kw;
mixer; pulp pump;water pump,control cabinet for pulping system,etc
2. Forming system
Consist of 1pc of forming platen and 1 pc of transfering platen.
Platen size:1100x470mm,4sets of 30-cell egg tray molds can be mounted on forming platen.
Forming efficiency:5-6cycles/min;
Equiped with vacuum auto draining system;auto cleaning system for the forming mold and auto control cabinet.
Egg box Machine can produce various trays/cartons with different moulds as per your specification or samp... Product Type: Egg Tray Machine
output :700pcs,1000pcs,1300pcs per hour
3. Drying system
Outline dimension:20080x2650x3600mm;
Single layer conveying chain;heated by section;multi burners;
Six layers drying line, energy saving and saving place
The temperature of each section can be adjusted independently;burners with French or Italian brand;
The energy for option: LPG,GAS,diesel oil,Equiped with auto control cabinet.
4. Stacking system
The finished products will be counted and stacked automatically after drying.
3.Contact Information for the Egg Tray Making Machine Price
If you need further information, please contact us freely, we will do our best to cooperate with you.
