Thermoplastic Road Marking Machine China Supplier
1.Machine introduction of thermoplastic road marking machine
The basic components of HTO-HXJ3 road marking machine is from the Graco company (United States). Our company combine with the requests of sports venues line and improve the technology. Line marker machine selects Honda engines which output is stable and strong. The machine has the following features as high flow capacity, wide application scope and easy operation. It is suitable for both the spray of ordinary paint and that of higher viscosity paint, such as oil paint, alkyd resin lacquer, nitro lacquer, epoxy resin lacquer and other kinds of paint.
Structure & Function
1. Airless spraying painting technology for which the high-pressure pump is driven by a gasoline engine has been adopted in the line marking machine to create clear, smooth, saturating and even limes, providing a high working efficiency.
2. Both sides of the spraying gun are equipped with a paint-limiting plates, ensuring the line free of raw edges. Such plates may be lift through a pulling line in steering, turning flexibly.
3. The spraying gun may be conveniently dismantled to change different nozzles and control the line width, suitable for common airless spraying for marks or labels.
4. Field line marker runs by pushing, with convenient turning, reliable orientation, and flexible turning.
5.Engine import from Honda Japan
2.Technical parameters of thermoplastic road marking machine
Model |
HTO-HXJ3 |
Honda engine power |
9.5Hp |
Marking rate |
0.5-3KM/H |
Common pressure |
10-20Mpa |
Max flow rate |
11.4L/Min |
Weight |
90Kg |
Appearance measurement |
750*420*660mm |
3.Contact information for thermoplastic road marking machine
If you need further information, please contact us freely, we will do our best to cooperate with you.
