Specifications
1.High efficiency permanent magnet generator.2.Low RPM.50RPM
3.Long service life.
4.Free energy generator
5.CE,ISO.
prmanent magnet generator(PMG) for sale
1. Technical Parameter :
5kw/50rpm PMG:
model |
5kw 50rpm |
generator type |
synchronous permanent magnet 3 phase AC |
magnetic steel material |
38SH NdFeB |
class of insulation |
B |
housing material |
cast iron / aluminium |
shaft material |
45# steel |
rated power |
5kw |
rated rotate speed |
50rpm |
rated voltage |
48VAC/96VAC/120VAC/220VAC/240VAC |
grade of protection |
IP54 |
weight |
285(cast iron)/209(aluminium) |
start up torque |
15.68(cast iron)/16.66(aluminium) |
rated torque at rated speed |
1346 |
number of poles |
46 |
10kw/50RPM PMG:
model |
10kw50rpm |
generator type |
synchronous permanent magnet 3 phase AC |
magnetic steel material |
38SH NdFeB |
class of insulation |
B |
housing material |
cast iron |
shaft material |
45# steel |
rated power |
10kw |
rated rotate speed |
50rpm |
rated voltage |
220VAC/240VAC/360VAC/380VAC |
grade of protection |
IP54 |
weight |
400 |
start up torque |
37.2 |
rated torque at rated speed |
2366 |
number of poles |
46 |
15kw/125RPM PMG:
model |
15kw125rpm |
generator type |
synchronous permanent magnet 3 phase AC |
magnetic steel material |
38SH NdFeB |
class of insulation |
B |
housing material |
aluminium |
shaft material |
45# steel |
rated power |
15kw |
rated rotate speed |
125rpm |
rated voltage |
220VAC/240VAC360VAC/380VAC |
grade of protection |
IP54 |
weight |
467 |
start up torque |
22.56 |
rated torque at rated speed |
1267 |
number of poles |
16 |
2.Fetures:
Low RPM.
Direct drive.
Low speed.
High efficiency.
Long life.
Easy to maintence.
35% wind energy utilization.
High performance price ratio.
Long use life.
3.generator models:
1KW50RPM(cast iron/aluminium),1KW100RPM(aluminium),2KW50RPM(cast iron/aluminium),3KW100RPM(aluminium), 5KW50RPM(cast iron/aluminium),5KW100RPM(aluminium), 10KW50RPM(cast iron),10KW100RPM (aluminium), 15KW125RPM(cast iron).
4.Introduction of our company:
We strive for providing customers with high quality wind turbine system with best price.The products are good reputed among all customers not only for the high quality guarantee but also for the superior services.All the members of JINFAN have innovate spirit and are ready for answering your questions.Our products have been exported to Asia,Europe,Austrlian and Ameirican.
The main products:horizontal axis wind turbine,,vertical axis wind turbine,wind and solar hybird system,solar panel, permanent magnet generator and other related products.
