Good Quality Beer Filling Equipment Price

Good Quality Beer Filling Equipment Price thumbnail-1
Good Quality Beer Filling Equipment Price thumbnail-2
Good Quality Beer Filling Equipment Price thumbnail-3
Good Quality Beer Filling Equipment Price thumbnail-4
Good Quality Beer Filling Equipment Price photo-1
Good Quality Beer Filling Equipment Price photo-2
Good Quality Beer Filling Equipment Price photo-3
Good Quality Beer Filling Equipment Price photo-4
US$ 10,000 - 12,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles, Cans
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for beer filling equipment
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage
Packaging Type Bottles, Cans
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number DGF
Dimension(L*W*H) 2900*2800*3100mm
Weight 2.5T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Good quality beer filling equipment price
1. Adopting crowning the caps with magnetic force, which passes the torque with powerful and constant magnet, and the torque can be adjusted to meet the need of many kind of plastic caps.

2. All the parts contact with liquid are made up of high quality stainless steel

3.This beer can filling machine is quite easy to be operated and maintained with the adopting of PLC control of frequency conversion timing.

4. Rotatory can-rinsing machine has the functions of not opening the valve and rinsing without can.

5. The sealing parts are all imported from foreign countries, which meets the requirement of the hygiene of the foodsafety

6. The   can filling seaming machine is a pop canned Beer in the digestion and absorption of advanced foreign and domestic sealing machine on the basis of independent development Of the can filling, sealing unit.

7. Adopting the way of filling by holding the necks of the cans, plus the function of pre-cover of the centralizing cover with high precise centralization, which ensure the right seating of mouth of the bottle and filling valve, with low liquid loss.

8.The can filling seaming machine easy to be maintained and used with the adopting of concentrating or automatic lubrication system and the structure of full-open protection.

Product display Good quality beer filling equipment price

Good quality beer filling equipment price



Good quality beer filling equipment price

Product Parameters Good quality beer filling equipment price
Model DGF
18186		 DGF
24248		 DGF
323212		 DGF
404015		 DGF
505018		 DGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
