Good Quality Pop Can Filling Production Line Price

US$ 1,000 - 9,999 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

Beverage

Packaging Type:

Cans

Zhangjiagang Jiazhou Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai for can filling production line price

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage

Packaging Type Cans

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Voltage 220V

Power 2.2KW

Place of Origin Jiangsu, China

Brand Name JZ

Model Number CGF

Dimension(L*W*H) 2800*2900*3000mm

Weight 2T

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

P/roduct information

Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description

The parts contact with the drink all made of good stainless steel (Minimum 304).

Driving and conveying System are driven by seamer.
Gas-controlling system receives and distributes the air/CO₂etc. to each point. All tie-ins with decompress valve and filters.
With centralized panel and touch screen. PLC and frequency inverter control.
Beer inlet is by a pneumatic adjusting valve. Inside the filling bowl, there is liquid level control sensor to balance the filling bowl level and pressure by integral control of the beer inlet valve.
Seaming roller and pressing head material: Stainless steel imported from Switzerland or Taiwan.
For beer, prefers to adopt Stainless steel instead of Cr12MoV to avoid eroding.

Product display

Product Parameters

Model	DGF 18186	DGF 24248	DGF 323212	DGF 404015	DGF 505018	DGF 606020
Head of washing, filling, sealing	18-18-6	24-24-8	32-32-8	40-40-10	50-50-18	60-60-20
Production capacity (bottle/hour)	3000-4000	5000-6000	7000-8000	9000-10000	11000-12000	15000
Suitable bottle diameter(mm)	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml
Filling precision	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm
Motor power	3.84kw	4.1kw	5.6kw	7.5kw	9kw	11kw
Filling pressure	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4
Overall dimension (mm)	2400×1900 ×2300	2800×2100 ×2300	4200×2300 ×2300	5000×2800 ×2400	5900×3100 ×2400	6500×3500 ×2400
Weight(Kg)	3000	4000	5000	7500	9000	11000
