aluminum can for juice or carbonated soft drinks filling and sealing machine
It is used for filling carbonated drink with juice pulp in PET bottle with plastic screw cap. we can supply the turnkey and installation running service.
Characteristic:
1.We use direct connection technology between air conveyor and in-feeding starwheel to substitute in-feeding screw and conveyor to ease the process of bottle-size-changing.
2.Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only arch board and starwheel such little nylon parts need to be changed.
3.Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4.Valve-opening device is droved by cylinder., with accurate action, rapid flow, highly filling precision, nicety liquid level. CIP system and controlling program are equipped to have rinsing in the place.
5.splint of starwheel using twist descending way to simplify the process of bottle-size-changing.
The machine applies to the production of carbonated drinks
Technical parameters
|
Model |
DCGFB18-18-6 |
DCGFB24-24-8 |
DCGFB32-32-12 |
DCGFB40-40-12 |
|
Production Capacity:500ml(B/h) |
4000-5000 |
7000-8000 |
11000-12000 |
15000-16000 |
|
Suitable Bottle Types(mm): |
Round or square square shaped bottle |
|||
|
PET Bottle Dimension: (mm) |
Bottle diameter:50-110 Height :150-330mm |
|||
|
Suitable Cap Standard: |
plastic screw Cap |
|||
|
Filling Precision |
≤±5mm |
|||
|
Filling Pressure(Mpa) |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
|
Rinsing Precision:(Mpa) |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
|
Installed Capacity:(L) |
3.5 |
4 |
6 |
8 |
|
Overall Size(mm)(L×W×H) |
2450×1800×2350 |
2780×2200×2350 |
3600×2650×2350 |
3800×2950×2400 |
|
Total Weight: (kg) |
3500 |
4500 |
5500 |
6500 |
