Help CenterBeer Can Filling Machine/tin Can Filling Machine
Related Products
-
Can Filling Line for Beer/milk/soft Drinks/soda DrinksNegotiableMOQ: 1 Set -
Non-carbonated Drinks Pop Cans Production LineNegotiableMOQ: 1 Set
-
Tin Filling Machine/equipment/device/systemNegotiableMOQ: 1 Set
-
Rotary Carbonated Can Filling MachineUS$ 1,000 - 20,000MOQ: 1 Unit
-
Zhangjiagang Beverage Machinery for Popcan Tin Filling Capping MachineNegotiableMOQ: 1 Set
Tin can beer filling machine Feature/ Automatic Beer Tin Can Filling Machine
Aluminum can beer filling machine
Tin Can Filling Machine For Liquid Drink
Description:
Tin Can Filling Machine For Liquid Drink is suitable for filling and sealing of carbonated drink beer and beverage in the industrial of pop can beverage field. The filling and seaming are of integral design. The principle of equal pressure filing is adopted. During filing, after the empty can reaches into the can lifting cylinder after passing through the pneumatic triplex parts, and the empty can is raised and the conical seal gasket under the filling valve is sealed. The position turning block of the filling valve turns the position and opens the valve under the action of another cylinder. The air is filled into the empty can to form equal pressure. From a large material barrel, the beer passes through 20 small conduits and flows into the empty can. When the liquid level in the empty can blocks the gas return pipe mouth, then the filling stops. Under the action of arm, the de-foaming valve will slowly discharge the air and pressure, the can supporting cylinder will continue to fall. After it is discharged, the can is sent to the sealing machine for sealing by the hook chain that runs synchronously. During the sealing, the sealing wheel carries out pre-sealing and then real sealing. After it is sealed, the can is pushed out by the beating head of the cap beating mechanism and then dialed by dial to the conveyor belt for conveying.
Technique paramete:
Model: |
GT4B20-4 |
GT4B36-8 |
Number of filling valves: |
20 |
36 |
Number of sealing valves: |
4 |
8 |
Suitable for diameter (mm): |
52.3~73mm |
|
Suitable doe height (mm): |
55~150mm |
|
Capable of production: |
≤180cans/min |
≤300cans/min |
Total power (kw): |
5 |
5.5 |
overall size:(mm) |
2700*1700 |
3500*2200 |
Total weight: (T) |
3 |
4 |
