RCGF Automatic Juice Small Bottling Filling Machine

1.Automatic Bottling 3 in 1 juice Bottle Filling Machine  adopt Rinsing/Filling/Capping 3-in-1

technology, PLC control, Touch Screen, it is mainly made of SUS304 or SUS316.

2.It is used for filling kinds of non-carbonated water, such as juice. still water,mineral water,

flavored water,spring water.

6. We can provide bottle blowing machine,bottle filling machine,labeling machine,

wrapping packing machine etc complete plant solution for PET bottle.with optional

capacityfrom 2,000-24,000BPH.

Model:

RCGF16-12-6

RCGF18-18-6

RCGF24-24-8

RCGF32-32-10

RCGF40-40-10

capacity :500ml

 4000

6000

8000

12000

16000

bottle shape:

roud or square

PET bottle: (mm)

(Bottle Diameter):φ50-.φ110mm   (Height):150-340mm

cap:

Plastic srew cap

filling precision:

≤±5mm

filling pressure:(Mpa)

 0.15-0.35

0.15-0.35

0.15-0.35

0.15-0.35

0.15-0.35

rinsing pressure:(Mpa)

0.2-0.25

0.2-0.25

0.2-0.25

0.2-0.25

0.2-0.25

Filling volume :(L)

 0.5

3.5

4

6

8

overall size:(mm)

 2150*1400
*2050

2450*1800
*2350

2780*2200
*2350

3600*2650
*2350

3800*2950
*2400

weight: (kg)

 2500

3500

4500

5500

6500
