Automatic electric welded mesh machine
- 15 Set / Sets per Month
- TIANJIN
- T/T
-
Spot welder welding machine vertical Point Welded Wire Mesh Machine
-
Pneumatic automatic diameter feeder, automatic net discharge and net falling, reinforced mesh welding machine
-
Pneumatic hanging wire automatic feeding diameter automatic net turning and netting steel mesh welding machine
-
Pneumatic hanging wire automatic net out and net down mesh welding machine for reinforced mesh
-
Mechanical automatic diameter feeding, automatic net out and net falling, reinforced mesh welding machine
-
Mechanical wire hanging, automatic diameter feeding, automatic net turning and netting, reinforced mesh welding machine
Product Details
| Condition: | New | Place of Origin: | Hebei, China | Brand Name: | JIAKE |
| Model Number: | DP-DNW-1 | Usage: | construction mesh and poultry cage | Voltage: | 380V,or according to client's voltage |
| Current: | 50A | Rated Duty Cycle: | 60% | Rated Capacity: | 2.2Kw |
| Dimensions: | 2.3m*1.3m*1.4m | Weight: | 1.5t | Certification: | CE |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Automatic electric welded mesh machinestable founction
firm welding electrodes
easy to operate
made in Anping, China
Automatic electric welded mesh machine
DP-DNW-1
DP-DNW-2
DP-DNW-3
Automatic electric welded mesh machine
Main parameters:
Model | DP-DNW-1 | DP-DNW-2 | DP-DNW-3 |
Mesh width | 914.4mm,1000mm | 1219.2mm,1524mm (4feet, 5feet) | 1219.2mm,1524mm, 1828.8mm,2133.6mm (4feet,5feet,6feet,7feet) |
Aperture/Pitch | 6.35mm-12.7mm | 12.7mm-101.6mm | 25.4mm-101.6mm |
Wire Diameter | 0.4mm-0.65mm | 0.65mm-1.8mm | 1.0mm-2.2mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage | ||
Motor | 2.2KW | 2.2KW | 2.2KW,4.0KW |
Welding Speed | ≤75 rows/min | ≤120rows/min | ≤80 rows/min |
Measurement of Machine | 2.3m*1.3m*1.4m | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight | 1.5T | 2.0T, 2.5T | 2.0T, 2.5T,3.0T, 3.5T |
Welded Transformer Capacity | 50kva*3 | 60kva*4; 60kva*5 | 60kva*4,60kva*5,60kva*6,60kva*7 |
Automatic electric welded mesh machine
Both longitude wire and cross wire was fed from wire coils automatically.It has advantages such as design reasonable, low noise, more stable, easier to operate.The mesh size is precise and the machine can set the width and length of mesh according to customer's requirement.
