Help CenterWelded Cage Making Machine
Related Products
Specifications
welded cage making machineCage diameter:300-2500mm
Programming and controlling by computer.
welded cage making machine
concrete pipe cage welding machine for cylindrical and prismatic piles with welded spiral and programmable pitch.
Two workers only are required.
Integrated production time.
Programming and controlling by computer.
Simple and efficient feeding system and functioning cycle.
The spacing of cross-coil can be adjusted, and the spacing of the line-rebar can be adjusted too.
Item & Model |
1250 |
1500 |
2000 |
2500 |
Cage diameter |
300-1250 |
500-1500 |
500-2000 |
500-2500 |
Max length of cage |
Standard 12m, or customized 15m, 18m, 21m, 24m, 27m, 30m, 33m, 36m |
|||
Max cage weight |
3000kg |
4500kg |
6000kg |
8000kg |
Line-rebar dia. |
12-40mm |
|||
Cross-coil dia. |
5-16mm |
|||
Space of cross-coil |
50-500mm adjustable |
|||
Rated power |
10KW |
11KW |
23KW |
23KW |
Overall dimension |
28*2.3*2.3m |
28*2.5*2.6m |
28*4.2*3.3m |
28*4.6*3.8m |
