Automatic wire mesh welding machines with all the auxiliary machines
Hebei Jiake Welding Equipment Co.,ltd are the professional manufacturer of wire mesh welding machines:
we could produce electric welded wire mesh machines, animal cage welding machine, fence mesh weding machine, reinforcing mesh welding machines, 3D panel machines and so on, too many types, could not be fully listed, please refer to some following:
All our wire mesh welding machines could be customized, please tell us your needs about the wire diameter, wire spacing ,mesh width and so on.
Some of the wire mesh welding machine main parameter
|
electric welded wire mesh machines 1. wire diameter 0.8-2mm 2. wire spaicng:12.7-50.8mm (1/2'-2') 3. mesh width:1.2192-1.8288m(48'-72') 4. line wire and cross wire in coil 5. roll mesh |
|
|
animal cage mesh welding machines 1. wire diameter:1.8-3mm 2.wire spacing:25-200mm 3. mesh width:1.2m 4. line wire and cross wire in coil 5.panel mesh 6. welding speed:80-100 cross wires/min |
|
|
full automatic construction mesh welding machine 1. wire diameter:2-4mm 2. wire spacing: 100-200mm 3. mesh width:1.2m 4. line wire and cross wire in coil 5.panel mesh 6. welding speed:80-100 cross wires/min |
|
|
CNC fence mesh welding machines JK-FM-2500B 1. wire diameter:3-6mm 2. wire spacing:50-200mm 3. mesh width:2.5m 4. line wire and cross wire pre-cut 5. panel mesh 6. STEP MOTOR output the mesh 7. welding speed:45-75 cross wires/min |
|
|
CNC fence mesh welding machines JK-FM-2500S 1. wire diameter:3-6mm 2. wire spacing:50-200mm 3. mesh width:2.5m 4. line wire and cross wire pre-cut 5. panel mesh 6. SERVO MOTOR output the mesh 7. welding speed:45-75 corss wires/min |
|
|
CNC construction mesh welding machines JK-FM-2500S+ 1. wire diameter:3-6mm 2. wire spacing:50-200mm 3. mesh width:2.5m 4. line wire COIL WIRE 5. cross wire pre-cut 6. panel mesh OR ROLL MESH 6. SERVO MOTOR output the mesh 7. welding speed:45-75 cross wires/min |
|
|
reinforcing mesh welding machines JK-RM-2500B 1. wire diameter 5-12mm 2. wire spacing:100-300mm 3. mesh width:2.5m 4. line wire and cross wire precut 5. panel mesh 6. servo motor output mesh 7. welding speed:45-65 cross wires/min |
|
|
steel bar mesh welding machines JK-FM-2500S+ 1. wire diameter:4-8mm 2. wire spacing:100-300mm 3. mesh width:2.5m 4. line wire and cross wire precut 5.panel mesh 6. servo motor ouput mesh 7. welding speed:45-75 cross wires/min |
|
