Reinforcing Mesh Making Machines
| Reinforcing mesh making machine | End products-reinforcing mesh, rebar mesh |
|
|
Reinforcing Mesh Making Machine Parameter:
| Model | JK-RM-2500B | JK-RM-2000B |
| Wire diameter | 5-12mm | 5-12mm |
| Mesh width(cross wire length) | 2.5m | 2.0m |
| Line wire length | max 12m | max12m |
| Welding electrode | 24pcs | 20pcs |
| line wire spacing | 100-300mm | 100-300mm |
| cross wire spacing | 50-300mm | 50-300mm |
| Welding transformer | 150KVA*12 | 150KVA*10 |
All our reinforcing mesh making machine could be customized such as wire diameter, mesh width, wire spacing and so on.
Reinforcing Mesh Making Machine including:
| 1 | Cross wire input hopper-step motor-automaitcally input the cross wire one by one |
|
| 2 | Line wire input device-panasonic servo motor-automatically input the line wire row by row(optional) | |
| 3. | Welding part-chromium zirconium copper electrode | |
| 4. | Mesh out device-Panasonic servo motor-automatically output the mesh | |
| 5. |
Electric control cabinet- Panosonic FPX series PLC, Panasonic servo motor, Weinview MT6071IE touch screen, Schneider low voltage apparatus, Panasonic servo driver, Meanwell power supply, Delta VE+ Omron encoder VFD, patent technology Circuit board |
|
| 6. | Cold rolling ribbed wire machines(optional) | |
| 7. | wire straightening and cutting machines(optional) | |
| 8. | water cooling system(optional) | |
| 9. | Brake motor with helical gear reducer | |
|
|
|
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Contact: Miss Daisy Lee
Skype:qq1815361000
Mobile/Wechat:+86 15324391556
Hebei JIAKE Welding Equipment Co.,Ltd
Address: Wire Mesh Industrial Zone, Anping County, Hebei Province, China
