Specifications
This new type machine adopts plunger and oil pipe lubricating structureNail Making Machine
Nail Making Machine Characteristics:
1. Z94 series C type Auto Nail Making Machine---Excellent, Durable, Low noise
2. The support of rotation axis adopts rolling bearing
3. Punch motion adopts the hinged plunger structure.
4. Main slipping surface adopts the oil bath lubrication and spraying lubrication, the other friction surfaces adopt lubricating pump centralized oiling.
5. Optimized cam work surface outline design. Manufactured by advanced process techniques so as to reduce the work noise.
Nail Making Machine Main parameters:
Items |
Unit |
Model |
|||
Z94-1C |
Z94-2C |
Z94-3C |
Z94-4C |
||
Max dia. of nail |
mm |
1.6 |
2.8 |
3.4 |
4.5 |
Min dia. of nail |
mm |
0.9 |
1.2 |
1.8 |
2.8 |
Max length of nail |
mm |
25 |
50 |
75 |
100 |
Min length of nail |
mm |
9 |
16 |
25 |
50 |
Designed output |
pcs/min |
400-480 |
300-350 |
280-320 |
240-280 |
Motor power |
KW |
1.5 |
2.2 |
3.0 |
4.0 |
Weight |
KG |
750 |
1250 |
1500 |
1800 |
Overall dimensions |
mm |
1350*950*1000 |
1650*1150*1100 |
2120*1200*1220 |
2400*1390*1340 |
We can customize the machine, please tell us your needs.
