Specifications
Black HDPE Geocell for Road Construction1. material: HDPE.
2. welding distance:330-1000mm.
3. height:50-250mm.
Black HDPE Geocell for Road Construction
Geocell is made of high intensity HDPE sheet which is welded together according to certain specification.They can be stretched and folded.
Geocell Feature
1. flexible to fold during transportation, stretching out.
2. filled with stone or concrete during service, forming into structure with powerful lateral confinement and rigidity.
3. used as cushion coat to strengthen loading capacity of weak ground or slope protection structure.
Geocell Technical Date
Item Model | Height (mm) | Welding distance (mm) | Sheet thickness (mm) | Tensile yield strength of the cell (MPa) | Seam peel strength (N) | |
smooth | textured | |||||
TGLG-50-400 | 50 | 400 | 1~1.1 | 1.4~1.5 | 20.0 | 500 |
TGLG-100-400 | 100 | 400 | 1~1.1 | 1.4~1.5 | 20.0 | 1000 |
TGLG-150-400 | 150 | 400 | 1~1.1 | 1.4~1.5 | 20.0 | 1500 |
TGLG-200-400 | 200 | 400 | 1~1.1 | 1.4~1.5 | 20.0 | 2000 |
TGLG-75-330 | 75 | 330 | 1~1.1 | 1.4~1.5 | 20.0 | 750 |
TGLG-100-330 | 100 | 330 | 1~1.1 | 1.4~1.5 | 20.0 | 1000 |
TGLG-150-330 | 150 | 330 | 1~1.1 | 1.4~1.5 | 20.0 | 1500 |
Notes:(1)welding distance can be made: 330mm, 400mm, 500mm,550mm or according to the demands (2)The special spec or size can be manufactured according to the demands of the contract | ||||||
Geocell Application
1. Fix railway ground.
2.Fix weak ground of roads and increase loading capacicity.
4.used to build the support block struction.
5.Act as independent wall, dock and break-water.
6.Treat desert, beach, riverbed and bank.
Geocell Photo Details
Geocell Production Line
Geocell Application
Geocell Loading Container
We are Geocell manufacturer in China, if you have any need, please feel free to contact me.
