Sawdust drum dryer/drying machine in good quality

Rotary dryer shows the features of perfect drying effect, easy operation, high efficiency and easy control of  drying. It takes advantage of the stability of roller and homogeneity of air.

This equipment makes the combination of roller and pipes which increase the drying strength and reduce the manual power. This is the ideal equipment for drying raw materials with high humility.

Rotary drying machine, also called pipeline type dryer, adopting twice circulate heating system, is our newly developed advanced drying equipments, and show the features of automatic feeding, high hot airflow speed, fully mixing of airflow and materials, big drying strength, lower dust and bigger drying capacity. Moisture in the raw materials of less than 40% can be drying one time to meet the requirement for coal bar production, which greatly reduced the labor intensity compared with commonly used dryer machine.

 1. After installation, start the blower, check the direction it runs and see if the suction at the material inlet is normal.

2. Tie up a bag whose both ends are open around the outlet of the dust catcher.

3. Feed the material to be dried to the hopper. Remove large grain in the material before drying, which will benefit drying speed.

4. Put fuel into the furnace and light it, start the blower. When the air temperature at the outlet of the blower get to 100°C, begin feeding and drying.

5. Large piece of the material at dregs-outlet must be removed, which is favorable to feeding.

    1.The bagasse dryer is mainly consist of the heating furnace, feeding port, rotating cylinder, separator, discharging port, air blower.

     1. Resonable structure

    2.Simple design, self-insulation, improve the heat efficiency to exceed 80%.

    3.Structure delicate, stable operation.

    4.Good drying performance, coal consumption <8kg when drying 1 ton material.

    5.The fuel can be coal, oil, natural gas etc, dry mass, granule and powder material.

    6.Reduce land area for 50% compared to single drum rotary dryer, so construction investment is saved 50%,power consumption saved 60%.

    7.Finished product moisture can be adjusted depends on requirement of client.

    8.Lower outlet tempreture, loonger dust removal using life.

    9.Drive by tug not gear.

    10.Finished product tempreture lower than 60°C, packing can be done continuously.

    1.Provide consultation services for customers, determine operational scales, and provide factory-establishing plan.
    2.Freely install, debug, and provide relevant technical training.
    3.Strict carry out three guarantees (guaranteed quality, guaranteed quantity and guaranteed repair), and so well technical consultation, and periodically do well technical follow-up.
    4.Ensure spare parts and components available adequately and timely.
    5.Mould Making and Accessories offered.
