Wire straightening machine
1) straighten raw steel wires
2) cut it into set length
3) SS, MS, GI wire
Wire straightening and cutting machine
This machine mainly consists of tray bar rack, straightening rack, tractor cutting device, base support, motor rotation facility and control box of electric appliances. This machine is applicable to straighten and cut all types of metal wire.
3-6mm
Model |
SC3-6 |
|
|
wire diameter |
3-6mm |
Cutting length |
30-6000mm |
Cut error |
±1mm |
Speed. |
30 m/min |
Straight motor |
2.2KW |
Cut motor |
1.5KW |
Overall size |
7.2*0.5*0.9M |
Weight |
350KG |
5-12mm
Wire Straightening and Cutting Machine |
Hydraulic cutting |
||
Wire diameter |
5-12mm |
Margin of error |
± 1mm |
cutting length |
Max 12m |
Power |
380V/50H |
speed |
30-40meters/minute |
Motor |
7.5kw 4kw
|
Gurantee
We are the number of trade assurance, we have USD36,000 to 100% refund of the Trade Assurance Amount for orders not meeting agreed delivery and quality terms contained in the contract.
