Carbon Steel Wire Rod From Top Manufacturer

US$ 400 - 650 MOQ: 1 Metric Ton

Key Specifications

Steel Grade:

SAE1008B

Standard:

AISI, ASTM, GB

Wire Gauge:

5.50mm-16.00mm

Tianjin Demetal International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade SAE1008B

Standard AISI, ASTM, GB

Wire Gauge 5.50mm-16.00mm

Place of Origin Tianjin, China

Application Construction

Alloy Or Not Non-alloy

Model Number SAE1008B

Brand Name OEM

Carbon Steel Wire Rod from top Manufacturer

Steel wire specificaions:

Material	45#, 60#, 65#, 70#, 72A, 72B, 82B, 65Mn
Diameter	0.15-6.5mm
Standard	DIN 17223, GB4357-2009, DIN EN 10270
Weight	According to the customers' requirements
Uses	To produce springs, steel wire ropes, brush and other uses
Packing	Coils Packing, spools packing, or according to the customers' requirements

Performance standard:

GB4357-2009 (National standard)

High Carbon Spring Steel Wire
Diameter(mm)	Tensile Strength ( Mpa )
Diameter(mm)	SL type	SM type	DM type	SH type	DH type
0.10			2710-3020		2800-3380
0.20			2500-2790		2800-3110
0.25			2420-2710		2720-3010
0.30		2307-2650	2370-2650	2660-2940	2660-2940
0.40		2270-2550	2270-2550	2560-2830	2570-2830
0.50		2200-2470	2200-2470	2480-2740	2480-2740
0.60		2140-2400	2140-2400	2410-2670	2410-2670
0.70		2090-2350	2090-2350	2360-2610	2360-2610
0.80		2050-2300	2050-2300	2310-2560	2310-2560
1.00	1720-1970	1980-2220	1980-2220	2230-2470	2230-2470
1.20	1670-1910	1920-2160	1920-2160	2170-2400	2170-2400
1.40	1620-1860	1870-2100	1870-2100	2110-2340	2110-2340
1.60	1590-1820	1830-2050	1830-2050	2060-2290	2060-2290
1.80	1550-1780	1790-2010	1790-2010	2020-2240	2020-2240
2.00	1520-1750	1760-1970	1760-1970	1980-2200	1980-2200
2.50	1460-1680	1690-1890	1690-1890	1900-2110	1900-2110
3.00	1410-1620	1630-1830	1630-1830	1840-2040	1840-2040
4.00	1320-1520	1530-1730	1530-1730	1740-1930	1740-1930
5.00	1260-1450	1460-1650	1460-1650	1660-1830	1660-1830
6.00	1210-1390	1400-1580	1400-1580	1590-1770	1590-1770
7.00	1160-1340	1350-1530	1350-1530	1540-1710	1540-1710
8.00	1120-1300	1310-1480	1310-1480	1490-1660	1490-1660
9.00	1090-1260	1270-1440	1270-1440	1450-1610	1450-1610
10.00	1060-1230	1240-1400	1240-1400	1410-1570	1410-1570
11.00		1210-1370	1210-1370	1380-1530	1380-1530
12.00		1180-1340	1180-1340	1350-1500	1350-1500
13.00		1160-1310	1160-1310	1320-1470	1320-1470
