Genset Main Technical Dat
Generator Model | JGC24GF |
Prime power | 24KW |
Standby power | 26.4KW |
Voltage | 400V/230V |
Frequency | 50HZ/1500 rpm |
Power factor | 0.8(lag) |
Governor type | Electric |
Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
Standby Power Rating : The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Voltage regulation
Voltage regulation maintained within ±0.5% as follow:Power factor Between 0.8~1.0 lag
From no load to full load, any steady loadSpeed droop variation under 4.5%
Frequency/Speed undulationChange load from 0-100%, Frequency/Speed Droop Ratio within 5%Load from 25-100%, any steady load Frequency/Speed undulation within 0.25%
Effect factor of telecom
Telephone Influence Factor (TIF): Less than 50
THF : Less than 2%
Cummins Diesel Engine
Technical Data
Engine Model | 4BT3.9-G2 |
Configuration | 4 cycle , 4 cylinders in line |
Aspiration | Turbocharged |
Bore×Stroke | 102 x120 mm |
Rated speed | 1500rpm |
Displacement | 3.9 L |
Compression Ratio | 16.5:1 |
Prime Power | 36KW |
Speed Governor | electrical |
Cooling System | Water-cooled , 40℃ Radiator As Standard |
Speed Stability (%) | ≤5% |
Fuel Consumption at 100% Load | 218g/kw.h |
Starter Motor | DC24V, |
