Home > Tools & Hardware > Hardware Accessories > Shackles > US Type Bolt and Nut Steel Drop Forged Safety Chain Shackle for Sales
US Type Bolt and Nut Steel Drop Forged Safety Chain Shackle for Sales
US$ 0.25 - 1,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Material:
Alloy Steel
Type:
US Type
Shape:
D
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Marine Boat Rubber FenderUS$ 100 - 5,000MOQ: 1 Piece -
30kva Magnetic Motor Generator for Sale From JiangsuUS$ 5,000 - 100,000MOQ: 1 Set
-
Good Price Marine Anchor Chain/ship Anchor Chain Nantong JakartaUS$ 1,000 - 90,000MOQ: 1 Chain
-
Electric Hydraulic Mooring Winch Low PriceUS$ 1,000 - 100,000MOQ: 1 Set
-
Solas Approved Common Totally Enclosed Lifeboat for ShipUS$ 15,000 - 35,000MOQ: 1 Set
Material
Alloy Steel
Type
US Type
Shape
D
Surface Treatment
Galvanized
Place of Origin
Jiangsu, China
Goods description
1.Item:Anchor shackles
2. size: 3/16 -- 4inch
3. Material of body: alloy steel
4 .Surface: Hot-Dipped,Galvanized,Electro Galvanized
5.MOQ: pieces
6.Delivery time: within 30 days
7.Package: gunny bags/cartons/customized
8.Payment: T/T,L/C,D/P
9.High qulity Competitive price and good service
10.Customers'special need is welcomed
Dimensions for JIS Type Screw Pin Chain Shackle Bow Shackle with Collar
| size(mm) | W.L.L(kgs) | B(mm) | D(mm) | L(mm) | d1(mm) | kg/pc |
| 5 | 90 | 10 | 10 | 18.5 | 5 | 0.026 |
| 6 | 150 | 12 | 11 | 25 | 6.5 | 0.028 |
| 8 | 250 | 14 | 15 | 31 | 8.5 | 0.065 |
| 10 | 400 | 18 | 17 | 36 | 10 | 0.080 |
| 12 | 600 | 24 | 23 | 46 | 13 | 0.200 |
| 16 | 800 | 30 | 32 | 59 | 17 | 0.495 |
| 20 | 1000 | 36 | 37 | 74 | 20 | 0.800 |
| 22 | 1500 | 43 | 43 | 86 | 23 | 1.260 |
| 25 | 2000 | 47 | 50 | 95 | 27 | 1.900 |
| 28 | 2500 | 55 | 56 | 110 | 30 | 2.650 |
| 32 | 3200 | 64 | 64 | 130 | 34 | 4.000 |
| 38 | 4200 | 76 | 76 | 145 | 40 | 7.000 |
| 44 | 6500 | 80 | 90 | 160 | 47 | 10.00 |
| 50 | 8000 | 90 | 100 | 185 | 53 |
12.50 |
