Cheapest Price 6 Ton Diesel Forklift Truck/small Capacity Diesel Forklift Trucks/double Mast Forklift Made in China

 QUALITY AND SERVICE ARE OUR LIFE

Contact information

Contact Person:Ivan Ji

Skype:jizufeng

Tel: 0086-513-68878985

Mobile:0086-18018402199

GOODS DESCRIPTION

Forklift Specification:

1)Load capacity: 3000kg

2)Load center:  500mm

3)Max. lifting speeds (full load): 470mm/s

4)Max. driving speeds: 20/19.5km/h

5)Gradeability: 15%

6)Lifting height: 3000mm(with optional)

7)Tilting angles (forward - backward): 6 / 12

8)Min. turning radius: 2480mm

9)Min. under-clearance: 110mm

10)Overall length: 3817mm

11)Overall width: 1230mm

12)Overall height (with mast retracted): 2055mm

13)Overall height (with mast extended): 4260mm

14)Overall height to overhead guard: 2085mm

15)Wheel base:   1700mm

16)Front tread:  1000mm

17)Rear tread:  970mm

18)Front tyre:  28x9-15

19)Rear tyre:  6.50-10

20)Total weight:  4350kg

21)Fork width:  125mm

22)Fork thickness:  45mm

23)Fork length: 1070mm(with optional)

24)Engine model: C490BPG/A490BPG/CA498/ISUZU C240/YANMAR 4TNE498

25)Power shift:Hydraulic transmission

26)Packing Details:3 SETS/20GP   &   5 SETS/40GP

27)Optional:Sideshifters/Fork Positioner/Paper Roll Clamps/Carton Clamps/Etc.

Product picture

 AFTER SERVICE TEAM IN SOUTH EAST ASIA

Payment Terms

30% deposit by T/T in advance, and the balance 70% by T/T 15days before departures the factory

or 100% irrevocable L/C at sight.

Our service

1.Standardization of Service “212"

2: response in 2 hours

1: provide solution in 1 day

2: solve complaint in 2 days

2.Installation Service

Installation Services are available with all JKDmachines. We dispatch technician to customer's factory for installation and preoperation of machines. ( Customers only

need to pay the airfare  and hotel )

3.Training Service

Our technician is available to your factory and offer training of how to use our machines.

As well, you may send your technician to our company to learn how to operate machines.

4.Quality Guarantee

We guarantee the quality of machine (e.g. processing speed and working performance

is the same as the data of samples making). We sign the agreement with detailed

technical data.

We arrange final test before shipment. We run the machine for a few days, and then

use customer's materials for test. After making sure machine is the best performance,

then make shipments.
