Help Center2016 Latest Technology 10 Ton Forklift Truck With High Quality Used in Indonesia
Related Products
-
New 4.5 Ton Forklift Price In Good ConditionUS$ 100 - 100,000MOQ: 1 Set -
New 25 Ton Forklift Price In Good ConditionUS$ 100 - 100,000MOQ: 1 Set
-
2000kg Four-Wheel Cheap DC/AC Electric Forklift CPD20US$ 1,000 - 1,000,000MOQ: 1 Set
-
1000kg Four-Wheel Cheap DC/AC Electric Forklift CPD10US$ 1,000 - 100,000MOQ: 1 Set
-
Good Quality Hydraulic Hammers for ExcavatorUS$ 1 - 10,000MOQ: 1 Set
QUALITY AND SERVICE ARE OUR LIFE
Contact information
Contact Person:Tina Jiang
Mobile:0086-15862735813
Skype:jiangyuna85
Forklift series
Diesel counterbalance forklift 1.8t-3.5t: CP(C)D18, CP(C)D20, CP(C)D25, CP(C)D30, CP(C)D35
Diesel counterbalance forklift 4.0t-10.0t: CPCD40, CPCD45, CPCD50L, CPCD50, CPCD60, CPCD70,CPCD80,CPCD100Diesel counterbalance forklift 3.3t-4.0t (specialized for timber): CP(C)D33, CP(C)D37, CP(C)D39,CP(C)D40L,CP(C)D40L
Diesel counterbalance forklift 4.0t-12.0t (specialized for stone): CPC40, CPC45, CPC50L, CPCD70,CPCD78,CPCD80, CPCD90, CPCD120;
Gasoline counterbalance forklift 2.0t-3.5t: CPQ(D)20, CPQ(D)25, CPQ(D)30, CPQ(D)35
LPG counterbalance forklift 2.0t-3.5t: CPQY(D)20, CPQY(D)25, CPQY(D)30, CPQY(D)35
LNG counterbalance forklift 2.0t-3.5t: CPT(D)20, CPT(D)25, CPT(D)30, CPT(D)35
DC electric counterbalance forklift 1.0t - 3.5t: CPD10, CPD15, CPD20, CPD25, CPD30, CPD35
Semi-AC electric counterbalance forklift 1.0t - 3.5t: CPD10J, CPD15J, CPD20J, CPD25J, CPD30J, CPD35J
Full-AC electric counterbalance forklift 1.0t - 3.5t: CPD10AC, CPD15AC, CPD20AC, CPD25AC, CPD30AC, CPD35AC; Electric counterbalance forklift (triple-pivot): CPD16S, CPD18S, CPD20S, CPD05
Electric reach forklift: CQD12, CQD16, CQD20, CQD25Tractor series: QYCD20, QYCD25, QSD20, QSD30, QSD20AC, QSD30AC
Electric stacker series: CDDZ12, CDDZ16, CDDZ20, CDDZ25, CTDZ12, CTDZ16, CTDZ20, CTDZ25
Van series: CBY-DF20, CBY-DF25, CBY-DF30, CBY-AC20, CBY-AC25, CBY-AC30, CBD15, CBD25, CBD30, CBD40,Etc.
If need any model, please feel free to contact me!
Forklift Specification
Load center distance | mm | 600 | |||
Lifting height | mm | 3000 | |||
Maximum height at work | mm | 4330 | |||
Mast tilt angle(Forwards/Backwards) | 6/12 | ||||
Hold under mast(min) | mm | 245 | |||
Turning radius(min) | mm | 3900 | |||
Travelling speed (max) | Unloaded | Km/h | 26 | ||
Loaded | 24 | ||||
Lifting speed (max) | Unloaded | mm/s | 290 | ||
Loaded | 350 | ||||
Lowering speeds(max) | mm/s | ≤600 | |||
Gradeability under full load (max) | % | 20 | |||
Dimensions | Length | Overall length | mm | 5480 | |
Length (without fork) | 4260 | ||||
Width | 2230 | ||||
Height | Closed mast height | 2850 | |||
Overhead guard height | 2600 | ||||
Wheelbase | mm | 2800 | |||
Wheel tread | Front | mm | 1600 | ||
Rear | 1700 | ||||
Tire | Front | - | 9.00-20-14PR | ||
Rear | - | 9.00-20-14PR | |||
Engine | Model | - | Xichai 6110 | ||
Displacement | L | 7.127 | |||
Rated power | Kw | 83 | |||
Revolution at rated power | Rpm | 2000 | |||
Maximum torque | Nm | 450 | |||
Revolution at maximum torque | rpm | 1450 | |||
Fuel tank capacity | L | 150 | |||
Fork size(LxWxT) | mm | 1220×175×80 | |||
Total weight | Kg | 12500 | |||
More details of forklift truck
After service team in south east Asia
Payment Terms
30% deposit by T/T in advance, and the balance 70% by T/T 15days before departures the factory
or 100% irrevocable L/C at sight.
Our service
1.Standardization of Service “212"
2: response in 2 hours
1: provide solution in 1 day
2: solve complaint in 2 days
2.Installation Service
Installation Services are available with all JKDmachines. We dispatch technician to customer's factory for installation and preoperation of machines. ( Customers only
need to pay the airfare and hotel )
3.Training Service
Our technician is available to your factory and offer training of how to use our machines.
As well, you may send your technician to our company to learn how to operate machines.
4.Quality Guarantee
We guarantee the quality of machine (e.g. processing speed and working performance
is the same as the data of samples making). We sign the agreement with detailed
technical data.
We arrange final test before shipment. We run the machine for a few days, and then
use customer's materials for test. After making sure machine is the best performance,
then make shipments.
