Transparent Thin Film Solar Panel Cell 250w Price List

Transparent Thin Film Solar Panel Cell 250w Price List thumbnail-1
Transparent Thin Film Solar Panel Cell 250w Price List thumbnail-2
Transparent Thin Film Solar Panel Cell 250w Price List photo-1
Transparent Thin Film Solar Panel Cell 250w Price List photo-2
US$ 50 - 5,000 MOQ: 5 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
NANEN
Model Number:
TY100-12M
Contact Supplier Request Quote Chat Now
Qingdao NanEn Brothers Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name NANEN
Model Number TY100-12M
Material Other
Size 156mm*156mm±0.5mm
Number of Cells 36pcs
Max. Power 250W

thin film solar cells



Model:TY100-12M

Physical  Characteristics

Dimension:     125mm×125mm±0.5mm

Thickness(Si):  200±20 μm



Front(-)                                                                   Back(+)

Blue anti-reflecting coating (silicon nitride);            Aluminum back surface field;

1.5mm wide bus bars;                                            2.0mm wide soldering pads;

Distance between bus bars: 51mm .                     Distance between bus bars :51mm .



Electrical Characteristics

Efficiency(%) 18.00 17.80 17.60 17.40 17.20 16.80 16.60 16.40 16.20 16.00 15.80 15.60
Pmpp(W) 4.33 4.29 4.24 4.19 4.14 4.09 4.04 3.99 3.94 3.90 3.86 3.82
Umpp(V) 0.530 0.527 0.524 0.521 0.518 0.516 0.514 0.511 0.509 0.506 0.503 0.501
Impp(A) 8.159 8.126 8.081 8.035 7.990 7.938 7.876 7.813 7.754 7.698 7.642 7.586
Uoc(V) 0.633 0.631 0.628 0.625 0.623 0.620 0.618 0.617 0.615 0.613 0.611 0.609
Isc(A) 8.709 8.677 8.629 8.578 8.531 8.478 8.419 8.356 8.289 8.220 8.151 8.083
