Specifications
Power distribution 50kWCapacity from 30kW to 300kW
ABB circuit breakers
Phoenix lightning arrestors
Customizable Sizes
Power distribution 50kW
Juneng AC Distribution Cabinet is suitable for solar power plant, according inverter capacity, the unit is used for supplying standardization interface to utility power grid. The cabinet has grid connect interface, voltmeter, ampere meter, grid side breaker, lightning protection device, Watt-hour meter and so on, the products has the features of high breaking capability, stable dynamic thermal ability, flexible electrical program, strong series and practice, innovative structure, high level of protection, it is convenient combination, easy installation and maintenance
Features
Capacity from 30kW to 300kW
Simplified system cabling structure
Easy operation and maintenance
Improved system reliability and security
ABB circuit breakers and Phoenix lightning arrestors
Full range of models, customizable and meets various requirements
Technical Specifications
Model |
Unit |
JNJP30K |
JNJP50K |
JNJP100K |
Operation Voltage |
Vac |
400 |
||
Rated capacity |
kW |
30 |
50 |
100 |
Number of AC Inputs |
1 |
1 |
1 |
|
Number of AC outputs |
1 |
1 |
1 |
|
Ingress Protection |
IP20 |
IP20 |
IP20 |
|
Operating Temperature |
°C |
-25~+60°C |
-25~+60°C |
-25~+60°C |
Relative Humidity |
% |
0~99% |
0~99% |
0~99% |
Working Altitude |
M |
5000 |
5000 |
5000 |
Lightning Protection Level |
II (IEC) |
II (IEC) |
II (IEC) |
|
Dimension |
Mm |
600*1500*500 |
600*1500*600 |
|
Weight |
kg |
120 |
130 |
150 |
