Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Energy System > DC Solar System

DC Solar System

Name: DC Solar System
Brand: Juneng
SKU: 140309336

US$ 632 - 633 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Anhui, China

Brand Name:

Juneng

Model Number:

JNISG01K

Contact Supplier Request Quote Chat Now

Hefei Jntech New Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Anhui, China

Brand Name Juneng

Model Number JNISG01K

Specification Mini

Application Home

Output Voltage (V) DC12V

Load Power (W) DC60W

Solar Power (W) 100wp

Work Time (h) 5

Specifications

DC Solar System
TUV CE approved Solar Module
Compact powerful funciton All In One Machine
DIY Installation

DC solar System

Your Benefits:

Power Supply: 9kWh per month

You can use: 2 sets of 11W lamps each work 4 hours per day

Plus 1 set of 42W fan work 6 hours per day

You can installation the system yourself

You can use power in romote area, without of costs of long distance cables like grid power net

You can use power free of money

You can save money when you use solar system even there already has grid power

You can use solar system everywhere and any time ony if have sun

You can use power without of noise, without of polution

Technical Info

System Model	Unit	JNISG01K
Support Loads
4 of 12V 15W lamps work 5 hrs/Day
Power Output
Power Supply	kWh	9kWh/M
Max power	W	DC120W
Output Voltage	V	DC12V
Solar Module
Peak Power	Wp	Mono Silicon 100Wp
Vmp	V	17.1V
Quantity	Pcs	1
All In One Machine (Combined with Controller/ Inverter/ Battery)
Controller DC input Voltage	V	12V
Controller DC input current	A	10A
Controller DC Output Power	V	DC12V, 120W
Inverter AC Output Power	W	/
Battery Capacity	/	AGM VRLA ,12V/100Ah
Machine Size	mm	L550D500H700
Weight	kg	42
Installation Method	/	Indoor Wall mounted/Floor Standing
Accessories	/	Switch, Breakers, meters, LCD display
Mounting Fittings
Installation Method	/	Standing Pole, Ground Insert
Pole Material	/	Φ10350cmδ4mm, hot galvanized metal
Mounting Accessories	/	Rail/End/Middle clip” Aluminum, Bolt: stainless steel
Cables	/	15M Sheathed wire RVV2×2.5mm²
Quantity	/	1 set
Complete system	Solar panel, installation pole and mounting accessories, All In One Machine with controller, inverter, battery, 15M cables

System Devices:

The solar generator you buy would including:

Solar Panel 100Wp, 1 piece

All In One Machine 1set

Solar Controller 12V 10A, 1 set

Solar battery: 12V/100Ah, 1 set

DC Breaker 2 sets

Installation pole: 2.5m Height with kits, 1 set

Electric terminals with switches, cables and all accessories, 1 set

Solar Home System Technical Characters:

High efficiency solar module from 100Wp to 300Wp, CE, UL, TUV approved

High conversion efficiency, reliable and multi functions All In One Inverter, which combine controller, inverter, battery and electricity distribution devices like breakers, switches, Volt meter in one body. Mostly convenient for installation, maintenance and usage.

Both DC and AC output, widely used for rural homes powering lamp, fan, washer, TV, cooler and so on

LCD Display timely monitoring power amount, voltage, current and so on

Compact design of All In One Inverter with full range of protections and lockable door for battery compartment, the system is powerful and safety for power use.

Anti corrosion mounting system, hot galvanized metal, aluminum material and stainless accessories sure its long life span

Easy DIY installation design, maximum smallized the complete system makes it’s easy for installation, operation and maintenance

Choosing deep cycle AGM VRLA or gel battery, with professional design, maximum its life span, safety and important of economy.

Which System you must have:

The system would be siutable used for small homes which have 4 small lamps, If you have more appliances, please choose other models, to know more about Off Grid Power System, please visit
