wood pellet grinder machine/wood crusher and grinders
This machine is a hammering type mill used to pulverize drugs, chemical materials, food staff and other materials with medium hardness and low viscosity. It is suitable for the suitable for the production in middle and small-batches or sample experiments in laboratories. Materials are fed into the pulverizing chamber by a helical conveyer, and pulverized instead of other energies of other energies of revolving parts of the machine.
The machine is simple in structure and the pulverizing chamber can be dismounted assemble and be dismounted and cleaned easily. All the parts in the chamber which contact materials are treated specially and corrosion resistama. As a result, in addition.
Any material ,drifted into grind chamber through feed bucket ,punched by knife edges and knife stands ,cut and grinded simultaneously by revolving and fixed knives, and due to the centrifugal force of revolving object ,automatically runs to exit.
Type no. |
Main power /KW |
Rotation speed R/min |
Max feed size /mm |
Discharging size /mm |
Capacity (T)/h |
Remark |
||||
JGXFJ-100 |
37 |
1600 |
1500 |
30-50 |
1 |
|
||||
JGXFJ-120 |
37 |
1600 |
2000 |
30-50 |
1.5 |
|
||||
Type no. |
Main power/KW |
Feeding motor power /KW |
Rota/min |
Feeding rotation speed /min |
Max feed size /mm |
Initial crushing size /mm |
Final crushing/mm |
Silo volume /CBM |
Capacity with single roller /T |
Capacity with double roller /T |
JGFSJ-250 |
45/37 |
4 |
1600 |
3-5 |
2500 |
50-80 |
30-50 |
7.5 |
8-10 |
5-8 |
JGFSJ-300 |
55/45 |
5.5 |
1600 |
3-5 |
3000 |
50-80 |
30-50 |
8 |
10-15 |
8-10 |
JGFSJ-350 |
75/55 |
5.5 |
1600 |
3-5 |
3000 |
50-80 |
30-50 |
9 |
15-20 |
13-15 |
JGFSJ-400 |
90/75 |
5.5 |
1600 |
3-5 |
3000 |
50-80 |
30-50 |
10 |
25-30 |
20-25 |
