Tiles Machine Manufacturer/
Roof Tiles Machine In South Africa
The full-automatic cement tile press includes the following parts:
| # | Product Name | |
| 1 | one bucket elevator | |
| 2 | one LK-350 vertical mixer | |
| 3 | one quantitative feeding mixer | |
| 4 | one MYW-8 main machine | |
| 5 | one hydraulic pallet truck | |
| 6 | one manual ridge/edge tile making machine | |
| 7 | 2000 pieces of steel roof tile pallets | |
| 8 | 5 pieces of plastic ridge tile moulds and 5 pieces of plastic edge tile moulds | |
Photo of the whole set cement tile press machine:
The full-automatic cement tile press machine is the most advanced innovative, cost-effective and
eco-friendly professional tile forming equipment by far.
Main technical parameters of the full-automatic concrete tile making machine:
| # | Main technical parameters | Details |
| 1 | Voltage | 380 V |
| 2 | Molding Cycle | 8-10 seconds / piece |
| 3 | Molding Pressure | 1800 Kilo Newton |
| 4 | Normal Roof Tile Size 1 | 420 x 330 x 15 mm |
| 5 | Normal Roof Tile Size 2 | 424 x 337 x 15 mm |
| 6 | Maximum Tile Size | 600 x 600 x 70 mm |
| 7 | Power of the Main Machine | 7.5 KW |
| 8 | Weight of the Main Machine | 5 Ton |
| 9 | Dimension of the Main Machine | 2600 x 1900 x 2500 mm |
| 10 | Output for Roof Tiles Per 8 Hours | 3000-3600 pieces |
Mix water, raw material such as cement, coal ash and sand up in proportion and feed the mixture evenly to
the main machine of the CNC concrete tile making machine, and then under the high pressure of a hydraulic
cylinder and a mould, semifinished concrete tiles that become concrete tiles after maintenance and painting
are produced. If different moulds such as terrazzo moulds are applied, terrazzos can be obtained.
The working flow of the cement tile press is as follows:
Close-up of roof tiles:
Please inform us of your specific requirements for better services:
1) Q: What kind of tiles you'd like to produce? Material and usage?
A: We can provide machines making concrete roof tiles, cement tiles, terrazzos, and bricks or blocks.
2) Q: What sizes would be normal for you?
A: For concrete roof tiles or terrazzos, maximum size achievable on MYW-8 is 600*600*70mm,
maximum size achievable on MYW-10 is 1230*640*20mm and 1000*1000*70mm.
3) Q: What's the production capacity you would like to achieve?
A: Our machine can achieve capacity of 3000 to 3600 pieces per 8 hours for concrete roof tiles,
2000 to 2800 pieces for terrazzo floor tiles.
4) Q: Working voltage you would like to use? 220V or 380V or 440V, etc.?
A: The voltage of our machines are 380V. But we can also make it at the voltage as per your local requirement.
5) Q: What's the MOQ of your machines?
A: The MOQ is 1 set.
6) Q: Where can we buy the machine's parts?
A: Our company can provide spare parts or components for you at any time.
Delivery of the concrete tile making machine:
High Quality is our Promise; Being Trustful is our Responsibility.
1) The quality guarantee is 12 months after installation and commissioning.
2) We will be responsible for malfunctions caused by the automatic tile machine itself or other quality problems.
3) The customer will be responsible for other misoperation or improper handling such as operation mistakes,
man-made problems.
Any way, we will help solve any problems the customer comes across in the operation and provide life-long
maintenance for the machine.
