1000kg Mechanical Ride-on Walk-behind Vibratory Roller
- Shanghai Port China
- T/T L/C D/P D/A
You May Like
-
SINOMACH LDS206 6Ton Tandem Vibratory Roller
-
New SINOMACH LSS214-3 14Ton Mechanical Drive Single Drum Vibratory Roller
-
LDD314H 14Ton Hydraulic Tandem Double Drum Vibratory Roller
-
LDD212H 12Ton Hydraulic Tandem Double Drum Vibratory Roller
-
New SINOMACH LSS208 8Ton Mechanical Drive Single Drum Vibratory Roller
-
SINOMACH LDD312H 12Ton Hydraulic Tandem Double Drum Vibratory Roller
Product Details
| Condition | New | Type | Double Drum Roller | |
| Travel Speed | 2.5km/h (Max. travel speed) | Grade Ability | 25% | |
| Brand Name | SINOMACH | Power(W) | 5.68kW | |
| Dimension(L*W*H) | 2050X900X1280mm | Weight | 1000kg | |
| Certification | ISO CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1000Kg Mechanical Walk-behind Double Drum Vibratory Roller
1.Application
The walk-behind vibratory rollers are small-size vibratory roller, applied to mending and maintaining various roads, expressway shoulders, roadside walk, parking area, sports ground and garden lawn. They are specially suited for compaction of narrow areas as pipeline channel and drainage trench, etc.
2. Main Features♦Famous brand Chinese Changfa CF186F inline direct-injection air-cooled diesel engine.
♦With both electrical and manual startup devices.
♦Double drum drive and double drum vibration.
♦There are two mud scraping boards besides the steel wheel.
♦The direction is changed by rubber-tires and the roller is operated by hand on the ground.
♦The seat is equipeed in YZC1 to make operation comfortable.
3.Technical Specifications
Model | YSZ08DB-I | YZC1 (with driver’s seat) |
Operating weight | 770kg | 1000kg |
Vibration amplitude | 0.25mm | 0.25mm |
Vibration frequency | 48Hz | 48Hz |
Centrifugal force | 12kN | 15kN |
Grade-ability | 25% | 25% |
Turning radius | 2700mm | 3900mm |
Max.travel speed | 2.5Km/h | 2.5Km/h |
Drum widthxDrum diameter | 600mmx405mm | 600mmx405mm |
Wheelbase | 470mm | 470mm |
Min. Ground clearance | 275mm | 275mm |
Diesel model | CF186F | CF186F |
Diesel power | 5.68kW | 5.68kW |
Diesel rotation speed | r/min | 2400 |
Overall dimensions | 2330x900x1050mm | 2050x900x1280mm |
Since the products is improved continuously. The specifications and instruction are subject to change without separate notice. | ||
