Simple structure Steel coils Cut to Length machine
l Technical Specification:
1. Coil material specification:
(1) Materials of Coiled Plate: Carbon steel,GI, Hot rolled plate/Cold rolled plate
(2) Thickness of Coiled Plate: 0.5-3.0 mm
(3) Width of Coiled Plate: 400mm-1300 mm
(4) Slitting length: 300mm~2500mm
(5) Coil Inner Diameter: Φ508mm
(6) Coil Outer Diameter: Φ1500 mm
(7) Max. Weight of Coiled Plate: 10 T
2. Other specification:
(1) Slitting Speed: 0-30 M/min
(2) Power supply: 380V/50Hz/3Ph
l Main composition:
1. Hydraulic expanding decoiler 1set
2. Slitting machine 1set
3. Simple stacker 1 set
4. Hydraulic system 1set
l Specification:
1. Hydraulic expanding decoiler:
(1) Main structure: it is composed of steel plate, four pieces arc panel, slider, main shaft, side plate, bearing and bearing base etc.
(2) Expansion diameter: Φ460mm~Φ520mm
(3) Loading capacity: 10T
(4) Push-pull swell-shrink core shaft, hydraulic cylinders:FA-Φ150mm
(5) Electronic Motor: Material feeding return, 7.5 KW cycloid needle motor with frequency converter
2. Slitting machine:
(1) Main structure: Servo controlled set-to-length, hydraulic shearer, 22KW servo motor, precision gear box,
(2) Servo controlled set-to-length: PLC Set-to-length,240mm×128mmLC interface, CNC motion controller, 0m/min~35m/min feeding speed, 2 feeding rollers, 15 leveling rollers,
(3) Hydraulic shearer: 4 sides, Cr12MoV material, HRC60±1ºhardness, hydraulic, hydraulic cylinders: FA-Φ100mm (2 set)
3. Simple stacker
(1) Welded rectangle steel
(2) Pneumatic stacking
(3) Stacking length: 3000mm
4. Hydraulic system
(1) Main structure: it is composed of steel plate,
(2) Force: E-class 15KW motor vane pump, volume: 30ML, normal pressure: 70kg/cm2, max pressure: 140kg/cm.
5. Electronic control system
(1) 3 phase 5 lines 380V, fluctuation within:+/-10%,control power supply: AC 220V
(2) Centralized control
(3) PLC & servo: domestic products, detecting element: Autonics,
Text display: Autoview, Other components: domestic products
LMS 2015 Cut-to-length line
