DFFILTRI PLF-C110x20 High Pressure Excavator Hydraulic Filter
Product Introduction
PLF series filter is installed on the different pressure lines of the hydraulic system;
it has high oil-passing capacity, low initial pressure loss, high dirt-holding capacity
and so on, which can meet the various requirements from the customers.
Order example
Technical Data
| Model | Nomal Flow Rate (L/min) | Nominal Pressure (bar) | Filtration Rating ( μm ) | Pressure Loss (bar) | Type of Indicator |
Cracking Pressure of the Bypass Valve (bar)
|
Model of Element | Connection | |
| Initial | Max | ||||||||
| PLF | 30 |
H=320
E=160
C=63 |
Optional 3,5,10,20,30...
βx(c) optional 75,100,200,1000, in accordance with ISO 16889 |
≤0.7 | 5 |
P=CS-V
Omit=Without Clogging Indicator |
Setting 6 bar | DF0030D* | Omit=Thread Connection |
| 60 | DF0060D* | ||||||||
| 110 | DF0110D* | ||||||||
| 160 | DF0160D* | ||||||||
| 240 | DF0240D* | F=Flanged Connection | |||||||
| 330 | DF0330D* | ||||||||
| 500 | DF0500D* | ||||||||
| 660 | DF0660D* | ||||||||
Note: 1)The sealing material is NBR, if FPM is needed, please contact us;
2)* represents filtration rating.
3)If inch threaded connection is needed, please contact us;
About Us
♦DFFILTRI was founded in 1995, since then we devoted ourselves to research,
develop and produce many kinds of hydraulic filters, air filters, hydraulic system
accessories, cleaning and filtration equipments,pump valve components.
DFFILTRI is our brand, which enjoys high popularity and it has successfully
achieved the position both in China and across the world.
♦DFFILTER filtration technology testing center covers a total area of 450 square
meters, of which,clean room area of 200 square meters, and cleanliness is up to
100,000 levels. The centre undertakes filtration technology inspection and testing
for in-house science research, production and industry service.
♦On-line particle counter of BETAB-HIAC/POYCO type (8000A/8000S) provided
by HIAC/POYCO company in USA, and its supporting machine"Multi-pass test"
and "single-pass test" implements ISO16889 new standard and other international
standards perfectly.
♦Testing center also has the developed equiment for filter performance testing,
which can make the comprehensive examination for filter element/cartridge
performance. These can insure that company’s filter with high capacity, long life,
high reliable in full compliance with our customer's requirement.
♦The testing centre can take 7 tests of hydraulic filter performance evaluation,
they are as follows:
ISO 2941 Verification of collapse/burst resistance
ISO 2942 Verification of fabrication integrity and determination of the first bubble point
ISO 2943 Verification of material compatibility with fluids
ISO 3723 Method for end load testing
ISO 3724 Verification of flow fatigue characteristics
ISO 3968 Evaluation of pressure drop versus flow characteristics
ISO 16889 Multi-Pass method for evaluating filtration performance
|
Qualification and Honor of DFFILTRI
|
Our Strategic Partners
P.S These are just part of our clients, in no particular order
