2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve

2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve thumbnail-1
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve thumbnail-2
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve thumbnail-3
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve thumbnail-4
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve thumbnail-5
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve photo-1
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve photo-2
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve photo-3
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve photo-4
2 Way 1/2'' Inches Motorized Electric Actuator Ball Valve photo-5
US$ 20 - 25 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Type:
Valves
Place of Origin:
Zhejiang, China
Model Number:
FH-T15-B2-A
Contact Supplier Request Quote Chat Now
Weihai Forward Hydraulics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Valves
Place of Origin Zhejiang, China
Model Number FH-T15-B2-A
Brand Name FORWARD

Basic Info.

Model NO.:FH-T15-B2-A

Connection Form:Thread
Channel:Straight Through Type

Structure:Floating Ball Valve
Type:Floating Ball Valve

Material:Brass
Export Markets:Global

Additional Info.

Trademark:Forward

Packing:Carton
Standard:Forward

Origin:China
HS Code:8481804090

Product Description

2 way 1/2'' inches motorized electric actuator ball valve(FH-T15-B2-A)

Product characteristics:
1. Mini size and perform reliably for small equipment
2. Easy to install
3. All metel gear
4. Long life time — 70000-100000 circles
5. Floating seal structure, good sealing, protection class IP67
6. Low working current, suitable for battery supply set
7. Manual override is safe and convenient
8. Passed CE certification and NSF61-G certification

Suitable conditions:
1. IC card water meters, heat energy meters, solar instrument.
2. The central air conditioning fan coil, fire sprinkler
3. Water saving irrigation, automatic control system, industrial mini automatic control equipment.
4. Agriculture irrigation equipment
5. Drinking water equipment, water heater, washing machine, ahw etc.
Product size  1/2"  (NPT/BSP 1/4"  3/8"  3/4"  1"  1-1/4"  ) Optional
Maximum working pressure 1.0MPa
Circulation medium Fluid, air
Rated voltage DC5V  DC12V  DC24  DC7-35V AC/DC9-35V AC/DC110-230V Optional
Wiring control methods CR2-01  CR2-02  CR3-01  CR3-02  CR3-03  CR3-04 CR4-01 CR5-01 CR5-02  CR7-01  CR7-02  CR7-03 CR7-04 Optional
Working current ≤500MA
Open/close time ≤5S
Life time 70000 times
Valve Body material Brass
Actuator material Engineering Plastics
Sealing material EPDM & PTFE
Actuator rotation 90 degree
Cable length 0.5M, 1.5M
Max. torque force 2 Nm
Environment temperature -15centigrade - 50 centigrade
Liquid temperature 2centigrade - 90centigrade
Manual override No
Indicator  No
